Titanium Sheet

EIL Approved Pure Titanium Sheet suppliers, View ASTM b265 Ti Alloy Plate Price Per Kg in India. Check Titanium Steel Coil Dimensions & Size, order custom size .125 / .012/ 3mm Ti Coil/ Strip

Titanium

On This Page

Specification Format of Titanium Sheet / Plate Titanium Steel Plate Sizes Titanium Clad Plate Weight per Unit Ti Alloy Sheet melting range CP Titanium Plate density Standard Specification of Titanium Plate Chemical Formula of Titanium Steel Coil Mechanical Strength of Polished Thin Titanium Sheet Equivalent Material of Ti Alloy Strips Titanium plate Applications

Gallery

Titanium Sheet in Detail

Specification

Features & Applications

To provide a full profiling service we use numerous profiling methods including:

Oxy-propane Flame Cutting
Plasma Plate Cutting
Laser Plate Cutting

Titanium plate Applications

Thermal & Nuclear Power Plants
Food & Dairy Plants
Oil & Gas Exploration
Paper Industries
Fertilizer Plant
Aerospace

Technical Data

Full Specifications

›Finishes & Forms

Specification Format of Titanium Sheet / Plate

ASTM Specification	ASTM B265 / ASME SA265
Length & Sizes	1000 mm x 2000 mm, 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1250mm x 2500mm, 1500mm x 3000mm to 6000mm, 2000mm x 4000mm to 6000mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm, 2m, 2.44m, 3m, 36" X 120" or 48" X 144", 4' x 8', Cut to size available
Hardness	Half Hard, Quarter Hard, Soft, Hard, Spring Hard etc.
Temper	Annealed
Finish	Cold rolled sheet (CR), 2B, 2D, Hot rolled plate (HR), BA NO(8), SATIN (Met with Plastic Coated)
Stock in form of	Plate, Sheet, hot rolled, cold rolled, annealed, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Coils, descaled, sheared, tread plate, Foils, Rolls, Plain Sheet, Flat Shim, Blank (Circle), soft annealed, Checker Plate
Thickness	0.1mm to 100 mm Thk
Export to	Brazil, Singapore, Indonesia, Canada, India, Ukraine, Thailand, Egypt, Ireland, Saudi Arabia, Oman, Dubai, Korea, Iran, Spain, USA, Peru, etc
Width	10-2500mm
Value Added Service	Annealed, Pickling, Polish, Cladding, Rolling, Cutting, Heat Treatment, Bending, Forging, Minor Fabrication Etc.
Profiling	To provide a full profiling service we use numerous profiling methods including: Oxy-propane Flame Cutting Plasma Plate Cutting Laser Plate Cutting
Test Report	Raw Materials Certificate Excellent corrosive resistance, good thermal resistance Strict Control from Raw Material to Finished EN 10204/3.1B 100% Radiography Test Report Third Party Inspection Report, etc Customer support after-sales service High special strength, high melt point
We offer a comprehensive services designed to add value to your project: plasma cutting, waterjet cutting, laser cutting, bending and mechanical processing, edge preparation, welding, sawing and shearing.	We offer a comprehensive services designed to add value to your project: plasma cutting, waterjet cutting, laser cutting, bending and mechanical processing, edge preparation, welding, sawing and shearing.

›Technical Data

Titanium Steel Plate Sizes

Scroll to see all columns →

Thickness / (in)	Size / (in)	Appx. Weight / Per Sheet (lbs)
.016	36 x 96	8.8
.020	36 x 96	11.0
.025	36 x 96	13.8
.032	36 x 96	17.7
.040	36 x 96	22.1
.050	36 x 96	27.7
.063	36 x 96	34.9
.071	36 x 96	39.3
.080	36 x 96	44.2
.090	36 x 96	49.8
.100	36 x 96	55.3
.125	36 x 96	69.1
.160	36 x 96	88.5
.187	36 x 96	103.4

Ti Alloy Sheet melting range

col_1
Melting Point of Titanium Plate
1,668 °C

CP Titanium Plate density

col_1
Titanium alloy Plate density
0.1630 lb/in³ / 4.512 g/cm³

Standard Specification of Titanium Plate

col_1	col_2	col_3
/ Sizes: Sheet & Plate / / .012 TO 4.00 X r/w X R/L / / Sizes: Coil / / .001 to .011 x R/W x R/L / /	GRADE	SPECIFICATIONS
/ Sizes: Sheet & Plate / / .012 TO 4.00 X r/w X R/L / / Sizes: Coil / / .001 to .011 x R/W x R/L / /	6AL-4V, 6AL-4V ELI	AMS-4911, 4907,4905, MIL-T-9046, ASTM-F136
/ Sizes: Sheet & Plate / / .012 TO 4.00 X r/w X R/L / / Sizes: Coil / / .001 to .011 x R/W x R/L / /		DMS-1592, GM-3103,12TM-B265
/ Sizes: Sheet & Plate / / .012 TO 4.00 X r/w X R/L / / Sizes: Coil / / .001 to .011 x R/W x R/L / /	6AL-2SN-4ZR-2MO	AMS,4919, MIL-T-9046, DMS-2275, AMS-T-9046
/ Sizes: Sheet & Plate / / .012 TO 4.00 X r/w X R/L / / Sizes: Coil / / .001 to .011 x R/W x R/L / /		GM-3104, B50TF21
/ Sizes: Sheet & Plate / / .012 TO 4.00 X r/w X R/L / / Sizes: Coil / / .001 to .011 x R/W x R/L / /	6AL-6V-2SN	AMS-4918, MIL-T-9046, DMS-1879, AMS-T-9046
/ Sizes: Sheet & Plate / / .012 TO 4.00 X r/w X R/L / / Sizes: Coil / / .001 to .011 x R/W x R/L / /	5AL-2.55N, 5-2.5 ELI	AMS-4909, 4910, MIL-T-9046, AMS-T-9046
/ Sizes: Sheet & Plate / / .012 TO 4.00 X r/w X R/L / / Sizes: Coil / / .001 to .011 x R/W x R/L / /	BAL-IMO-1V	AMS-4915, 4916, DMS-1784
/ Sizes: Sheet & Plate / / .012 TO 4.00 X r/w X R/L / / Sizes: Coil / / .001 to .011 x R/W x R/L / /	CP-GRADES 1,2,3,4	AMS-4900, 4902
/ Sizes: Sheet & Plate / / .012 TO 4.00 X r/w X R/L / / Sizes: Coil / / .001 to .011 x R/W x R/L / /		MIL-T-9046, AMS-T-9046, DMS-1536, ASTM-B265
/ Sizes: Sheet & Plate / / .012 TO 4.00 X r/w X R/L / / Sizes: Coil / / .001 to .011 x R/W x R/L / /	15V-3CR-3SN-3AL	AMS-4914

Equivalent Material of Ti Alloy Strips

col_1	col_2	col_3
STANDARD	WERKSTOFF NR.	UNS
Titanium Gr. 2	3.7035	R50400
Titanium Gr. 5	3.7165	N56400

Check Where Ashtapad Overseas Supplies

col_1	col_2
Titanium hot rolled 12.0x2000x3000 mm plate	Kuwait, Brazil, Saudi Arabia (KSA), South Africa
2.5x1200x3000 mm CP Titanium Plate	Russia, Dubai, Malaysia, Netherlands
Pure Titanium Superalloy Mesh Plate	Poland, Ellington -United States, Canada, UK
mirror polished 6mm titanium anode plate	UK, Nigeria, Australia, Philippines
pure titanium strips	Los Alamos -Mexico, Philippines, Taiwan, Malaysia
polished Factory astm b265 titanium foil	Romania, Malaysia, Japan, Europe
50mm titanium alloy sheet	Malaysia, UAE, Europe, United Kingdom -UK
titanium clad sheet	Thailand, Malaysia, Germany, Czechia
High Purity Mirror Surface 0.05mm Thickness pure titanium foil	Iran, Singapore, Italy, Chile
Cold Forming Titanium Sheet	Philippines, Belgium, Indonesia, Dammam -KSA
05mm Pure Titanium Ti6al4v Sheet	Europe, Thailand, France, Qatar
Titanium Strip For Surgical Implant	NY 12203 (USA), Malaysia, South Korea, Singapore
High Quality 1.0mm Titanium Plates	Bangladesh, Finland, USA, Malaysia
High purity polished titanium Foil 0.1MM	Hong Kong, UAE, Malaysia, Oman
titanium ams 4911 plate/Sheet	Norway, Malaysia, Turkey, United Arab Emirates (UAE)
0.1mm titanium strip	Mexico, UK, Spain, Egypt
titanium coil plate	Malaysia, China, Colombia, Sweden
0.1mm thick titanium coil	Canada, Singapore, Malaysia, Philippines
asme sb 265 titanium sheet	Singapore, Singapore, South Africa, Bahrain

›Dimensions & Weight

Titanium Clad Plate Weight per Unit

Thickness	Plate Weight per Unit Area	Density
3/16 inches	0.06000 lbs/in²42.184176 kg/m²	0.315 lbs/in³8.72 g/cm³
1/4 inches	0.08 lbs/in²56.245568 kg/m²	0.315 lbs/in³8.72 g/cm³
3/8 inches	0.121 lbs/in²85.0714216 kg/m²	0.315 lbs/in³8.72 g/cm³
1/2 inches	0.161 lbs/in²113.1942056 kg/m²	0.315 lbs/in³8.72 g/cm³
5/8 inches	0.196 lbs/in²137.8016416 kg/m²	0.315 lbs/in³8.72 g/cm³
3/4 inches	0.235 lbs/in²165.221356 kg/m²	0.315 lbs/in³8.72 g/cm³
7/8 inches	0.274 lbs/in²192.6410704 kg/m²	0.315 lbs/in³8.72 g/cm³
1 inches	0.313 lbs/in²220.0607848 kg/m²	0.315 lbs/in³8.72 g/cm³
1 1/4 inches	0.391 lbs/in²274.9002136 kg/m²	0.315 lbs/in³8.72 g/cm³
1 1/2 inches	0.47 lbs/in²330.442712 kg/m²	0.315 lbs/in³8.72 g/cm³
1 3/4 inches	0.549 lbs/in²385.9852104 kg/m²	0.315 lbs/in³8.72 g/cm³
2 inches	0.627 lbs/in²440.8246392 kg/m²	0.315 lbs/in³8.72 g/cm³
2 1/4 inches	0.705 lbs/in²495.664068 kg/m²	0.315 lbs/in³8.72 g/cm³
2 1/2 inches	0.784 lbs/in²551.2065664 kg/m²	0.315 lbs/in³8.72 g/cm³
2 3/4 inches	0.862 lbs/in²606.0459952 kg/m²	0.315 lbs/in³8.72 g/cm³
3 inches	0.941 lbs/in²661.5884936 kg/m²	0.315 lbs/in³8.72 g/cm³

Metric Dimensions

Surface finish	Thickness (mm)	Width (mm)
2B – Cold rolled, heat treated, pickled, skin passed	0.25–8.0	max. 2032
2D – Cold rolled, heat treated, pickled	0.4–6.35	max. 1524
2E – Cold rolled, heat treated, mechanically descaled	0.4–8.0	max. 2032
2R – Cold rolled, bright annealed	0.25–3.5	max. 1524
2H – Work hardened	0.4–6.35	max. 1524
Polished, brushed	0.5–4.0	max. 1524

Imperial Dimensions

Surface finish	Gauge (in)	Width (in)
2B – Cold rolled, heat treated, pickled, skin passed	10–24	max. 72*
2D – Cold rolled, heat treated, pickled	12–24	max. 60
BA Mexinox only	18–28	max. 48
Polished (not brushed)	11–24	max. 60
Temper rolled Mexinox only	13–29	max. 48

›Material Properties

Chemical Formula of Titanium Steel Coil

Scroll to see all columns →

col_1	col_2	col_3	col_4	col_5	col_6	col_7	col_8	col_9
Grade	Ti	C	Fe	H	N	O	Al	V
Ti Grade2	99.2 min	0.1 max	0.3 max	0.015 max	0.03 max	0.25 max	-	-
Ti Grade5	90 min	-	0.25 max	-	-	0.2 max	6 min	4 min

Mechanical Strength of Polished Thin Titanium Sheet

col_1	col_2	col_3	col_4	col_5	col_6
Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Titanium Gr. 2	4.5 g/cm3	1665 °C (3030 °F)	Psi - 49900 , MPa - 344	Psi - 39900 , MPa - 275	20 %
Titanium Gr. 5	4.43 g/cm3	1632 °C (2970 °F)	Psi - 138000 , MPa - 950	Psi - 128000 , MPa - 880	14 %
