Titanium Grade 5 Sheet

We are Titanium Grade 5 Sheet Suppliers in India, View Astm B265 Ti Gr 5 Plate Price Per Kg, Ready stock of Cp Grade 5 Titanium Coil, WNR 3.7165 Foil, Check UNS N56400 Hot Rolled Strips Dimensions

Titanium

On This Page

Material Specification of Titanium Grade 5 Sheet / Plate Composition Standard of Titanium Alloy Gr 5 Sheet Mechanical Strength of UNS N56400 Clad Plate Ti Gr 5 Strips Equivalent Material Grade 5 Ti Chequered Plate Electrical Properties Titanium Alloy Gr 5 Foil Modulus of Elasticity Sizes of UNS N56400 Plate Weight Chart of Gr 5 Ti Alloy Plate Physical Properties of Titanium Grade 5 Sheet Heat treatment of Cp Grade 5 Titanium Sheet Titanium Grade 5 Sheet Features Applications of Gr 5 Ti Alloy Plate Titanium Gr 5 Cold Rolled Plate Charpy Impact and Shear Modulus

Gallery

Titanium Grade 5 Sheet in Detail

Specification

Features & Applications

To provide a full profiling service we use numerous profiling methods including:

Oxy-propane Flame Cutting
Plasma Plate Cutting
Laser Plate Cutting

Titanium Grade 5 Sheet Features

Excellent Strength To Weight Ratio.
Low Thermal Conductivity
High Modulus Of Elasticity
High Corrosion Resistance
Good Weldability And It Is Heat Treatable

Applications of Gr 5 Ti Alloy Plate

Chemical processing
Fasteners
Aerospace
Jewellery
Chemical processing
Spring wire

Technical Data

Full Specifications

›Technical Data

Material Specification of Titanium Grade 5 Sheet / Plate

ASTM Specification	ASTM B265 / ASME SA265
Length & Sizes	1000 mm x 2000 mm, 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1250mm x 2500mm, 1500mm x 3000mm to 6000mm, 2000mm x 4000mm to 6000mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm, 2m, 2.44m, 3m, 36" X 120" or 48" X 144", 4' x 8', Cut to size available
Stock in form of	Shim Sheet, Plate, Blank (Circle), hot rolled, cold rolled, Sheet, annealed, Strip, Flats, Rolling Sheet, Flat Sheet, Flat Shim, Clad Plate, Foils, Rolling Plate, descaled, sheared, Rolls, Plain Sheet, soft annealed, Coils, tread plate, Checker Plate
Width	10-2500mm
Hardness	Quarter Hard, Half Hard, Hard, Soft, Spring Hard etc.
Temper	Annealed
Finish	2B, Cold rolled (CR), 2D, BA NO(8), Hot rolled (HR), SATIN (Met with Plastic Coated)
Value Added Service	Polish, Annealed, Heat Treatment, Pickling, Cutting, Bending, Rolling, Forging, Cladding, Minor Fabrication Etc.
Profiling	To provide a full profiling service we use numerous profiling methods including: Oxy-propane Flame Cutting Plasma Plate Cutting Laser Plate Cutting
Thickness	0.1mm to 100 mm Thk
Export to	Canada, India, Ukraine, Thailand, Brazil, Singapore, Indonesia, Egypt, Ireland, Saudi Arabia, Oman, Dubai, Korea, Iran, Spain, USA, Peru, etc
Test Report	Raw Materials Certificate Excellent corrosive resistance, good thermal resistance Strict Control from Raw Material to Finished EN 10204/3.1B 100% Radiography Test Report Third Party Inspection Report, etc Customer support after-sales service High special strength, high melt point

Ti Gr 5 Strips Equivalent Material

col_1	col_2	col_3
STANDARD	WERKSTOFF NR.	UNS
Titanium Gr. 5	3.7165	N56400

Grade 5 Ti Chequered Plate Electrical Properties

Electrical Resistivity	0.000178 ohm-cm	0.000178 ohm-cm_2	col_4
Magnetic Permeability	1.00005	1.00005	at 1.6kA/m
Magnetic Susceptibility	3.3e-006	3.3e-006	cgs/g

Titanium Alloy Gr 5 Foil Modulus of Elasticity

col_1
Modulus of Elasticity
113.8 GPa

Sizes of UNS N56400 Plate

Thickness / (in)	Size / (in)	Appx. Weight / Per Sheet (lbs)
.016	36 x 96	8.8
.020	36 x 96	11.0
.025	36 x 96	13.8
.032	36 x 96	17.7
.040	36 x 96	22.1
.050	36 x 96	27.7
.063	36 x 96	34.9
.071	36 x 96	39.3
.080	36 x 96	44.2
.090	36 x 96	49.8
.100	36 x 96	55.3
.125	36 x 96	69.1
.160	36 x 96	88.5
.187	36 x 96	103.4

Physical Properties of Titanium Grade 5 Sheet

Density	Melting Point	Coefficient of Expansion	Modulus of Rigidity	Modulus of Elasticity
4.42 g/cm³	1650 °C	9.0 μm/m °C (20 – 100 °C)	40 – 44 kN/mm²	105 – 120 kN/mm²
0.16 lb/in³	3000 °F	5.0 x 10-6 in/in °F (70 – 212 °F)	5800 – 6380 ksi	15230 – 17405 ksi

Heat treatment of Cp Grade 5 Titanium Sheet

Condition	Type	Temperature	Time	Cooling
Annealed	Stress Relieve	480 °C (900 °F)	2 Hr	Air
Spring Temper	Stress Relieve	250 °C (480 °F)	0.5 Hr	Air

Titanium Gr 5 Cold Rolled Plate Charpy Impact and Shear Modulus

col_1	col_2
Charpy Impact	17 J
Shear Modulus	44 GPa

Material Supplied In Following Countries

col_1	col_2
Titanium Alloy Grade 5 Cold Rolled Plate	Malaysia, Czechia, Germany, Thailand
ti-6al-4v grade 5 titanium plate sheet 20mm	Finland, Malaysia, USA, Bangladesh
grade 5 titanium ti 6al 4v titanium ams 4911 plate/Sheet	China, Sweden, Colombia, Malaysia
grade 5 titanium armor plate	Philippines, Malaysia, Taiwan, Los Alamos -Mexico
astm b265 ti6al4v grade 5 titanium custom cut plate	Dubai, Netherlands, Malaysia, Russia
Ti-6al-4V Grade 5 Titanium Plate for Industrial	Singapore, Bahrain, South Africa, Singapore
ASTM B265 Titanium Grade 5 Plate 2b Finish	UAE, United Kingdom -UK, Europe, Malaysia
astm b265 6.5mm ti6al4v grade 5 titanium plate	Brazil, South Africa, Saudi Arabia (KSA), Kuwait
Thickness 0.8mm ti6al4v Grade 5 Titanium alloy Sheet	UK, Egypt, Spain, Mexico
Titanium Ti-6Al-4V Grade 5 Strip	Nigeria, Philippines, Australia, UK
grade 5 titanium plate sheet 3/4/5mm thickness	Malaysia, Europe, Japan, Romania
ASTM B265 Titanium Alloy Grade 5 Shim Sheet	Singapore, Chile, Italy, Iran
5mm thick grade 5 titanium sheet 1mmx1000mmx200mm	Malaysia, United Arab Emirates (UAE), Turkey, Norway
titanium strip grade 5 for industry and medical	Belgium, Dammam -KSA, Indonesia, Philippines
4mm titanium alloy Ti 6al4v grade 5 titanium sheet	Malaysia, Singapore, South Korea, NY 12203 (USA)
Strip 05mm ti6al4v astmb265 grade 5	Thailand, Qatar, France, Europe
0.5mm titanium grade5 alloy foil	Ellington -United States, UK, Canada, Poland
Cold rolled titanium metal grade 5 coils	Singapore, Philippines, Malaysia, Canada
grade 5 6al4v titanium strip	UAE, Oman, Malaysia, Hong Kong

›Material Properties

Composition Standard of Titanium Alloy Gr 5 Sheet

Scroll to see all columns →

col_1	col_2	col_3	col_4	col_5	col_6	col_7	col_8	col_9
Grade	Ti	C	Fe	H	N	O	Al	V
Ti Grade5	90 min	-	0.25 max	-	-	0.2 max	6 min	4 min

Mechanical Strength of UNS N56400 Clad Plate

col_1	col_2	col_3	col_4	col_5	col_6
Element	Elongation	Density	Melting Point	Yield Strength (0.2%Offset)	Tensile Strength
Titanium Gr. 5	14 %	4.43 g/cm3	1632 °C (2970 °F)	Psi - 128000 , MPa - 880	Psi - 138000 , MPa - 950

›Dimensions & Weight

Metric Dimensions

Surface finish	Thickness (Millimeter)	Width (Millimeter)
2B – heat treated, Cold rolled, pickled, skin passed	0.25–8.0	max. 2032
2D – heat treated, Cold rolled, pickled	0.4–6.35	max. 1524
2E – heat treated, Cold rolled, mechanically descaled	0.4–8.0	max. 2032
2R – Cold rolled, bright annealed	0.25–3.5	max. 1524
2H – Work hardened	0.4–6.35	max. 1524
Polished, brushed	0.5–4.0	max. 1524

Imperial Dimensions

Surface finish	Gauge (in)	Width (in)
2B – Heat treated, Cold rolled, pickled, skin passed	10–24	max. 72*
2D – Heat treated, Cold rolled, pickled	12–24	max. 60
BA Mexinox only	18–28	max. 48
Polished (not brushed)	11–24	max. 60
Temper rolled Mexinox only	13–29	max. 48

Weight Chart of Gr 5 Ti Alloy Plate

Thickness	Plate Weight per Unit Area	Density
3/16 inches	0.06000 lbs/in² / 42.184176 kg/m²	0.315 lbs/in³/ 8.72 g/cm³
3/8 inches	0.121 lbs/in²85.0714216 kg/m²	0.315 lbs/in³8.72 g/cm³
1/4 inches	0.08 lbs/in²56.245568 kg/m²	0.315 lbs/in³8.72 g/cm³
1/2 inches	0.161 lbs/in²113.1942056 kg/m²	0.315 lbs/in³8.72 g/cm³
3/4 inches	0.235 lbs/in²165.221356 kg/m²	0.315 lbs/in³8.72 g/cm³
5/8 inches	0.196 lbs/in²137.8016416 kg/m²	0.315 lbs/in³8.72 g/cm³
7/8 inches	0.274 lbs/in²192.6410704 kg/m²	0.315 lbs/in³8.72 g/cm³
1 1/4 inches	0.391 lbs/in²274.9002136 kg/m²	0.315 lbs/in³8.72 g/cm³
1 inches	0.313 lbs/in²220.0607848 kg/m²	0.315 lbs/in³8.72 g/cm³
1 1/2 inches	0.47 lbs/in²330.442712 kg/m²	0.315 lbs/in³8.72 g/cm³
2 inches	0.627 lbs/in²440.8246392 kg/m²	0.315 lbs/in³8.72 g/cm³
1 3/4 inches	0.549 lbs/in²385.9852104 kg/m²	0.315 lbs/in³8.72 g/cm³
2 1/4 inches	0.705 lbs/in²495.664068 kg/m²	0.315 lbs/in³8.72 g/cm³
2 3/4 inches	0.862 lbs/in²606.0459952 kg/m²	0.315 lbs/in³8.72 g/cm³
2 1/2 inches	0.784 lbs/in²551.2065664 kg/m²	0.315 lbs/in³8.72 g/cm³
3 inches	0.941 lbs/in²661.5884936 kg/m²	0.315 lbs/in³8.72 g/cm³
