Stainless Steel Strip

View Stainless Steel Strip Specification. We are Supplier and stockist of ASTM a240 SS brushed/ polished Cold Rolled Strips. Available Sizes in 18 gauge, 22 gauge SS Strips in finish 2B.

Stainless Steel

On This Page

Specification of Stainless Steel Strip Chemical Composition of perforated stainless steel strips Mechanical Properties of SA240 SS Thin Strips Equivalent Grade of stainless steel seam strips Available Size of SS Hot Rolled Strip Tolerance of Width of SS 304 Strip Coil

Gallery

Stainless Steel Strip in Detail

Specification

Features & Applications

Available Size of SS Hot Rolled Strip

Width: 16.0~609.6 mm
Thickness: 2.5~10.0 mm
Available Steel Grade: 304, 304L, 316L
Surface Finish: No.1

Technical Data

Full Specifications

›Technical Data

Specification of Stainless Steel Strip

col_1	col_2
Thickness	1.5mm-6.0mm
Material Grade	Grade 202 & 304 CR material
Application	Fabrication, Construction
Material	Stainless Steel
Export to	Brazil, Singapore, Indonesia, Canada, India, Ukraine, Thailand, Egypt, Ireland, Saudi Arabia, Oman, Dubai, Korea, Iran, Spain, USA, Peru, etc
Surface Finish	Polished
Width	200mm-800mm

Check What We Supply if you belong to following locations

col_1	col_2
decorative stainless steel strips	Dammam -KSA, Indonesia, Philippines, Belgium
0.2mm 0.3mm precision stainless steel strip	Qatar, France, Europe, Thailand
22 gauge stainless steel strips	Czechia, Germany, Thailand, Malaysia
430 1.0mm Thick Half Hard Stainless Steel Strip	Malaysia, USA, Bangladesh, Finland
magnetic stainless steel knife strip	South Africa, Saudi Arabia (KSA), Kuwait, Brazil
316L ss steel strip 2-10mm thick	Bahrain, South Africa, Singapore, Singapore
stainless steel shim stock strips	Philippines, France, Australia, UK, Nigeria
8~600 mm Stainless Steel Strips for Decoration and construction	Oman, Malaysia, Hong Kong, UAE
strip 2B SS rolls 304	Chile, Italy, Iran, Singapore
cold rolled 2B surface full hard 420 stainless steel strip	United Arab Emirates (UAE), Turkey, Norway, Malaysia
stainless steel seam strips	Netherlands, Malaysia, Russia, Dubai
hot rolled 5mm 310s stainless steel strip	Egypt, Spain, Mexico, UK
magnetic stainless steel strips	United Kingdom -UK, Europe, Malaysia, UAE
430 stainless steel strapping cold rolled	UK, Canada, Poland, Ellington -United States
Slit edge spring stainless steel strip	Philippines, Malaysia, Canada, Singapore
thin stainless steel strips	Europe, Japan, Romania, Malaysia
321 stainless steel packing tape strips	Sweden, Colombia, Malaysia, China
thickness 201 stainless steel strip for chemical equipment	Malaysia, Taiwan, Los Alamos -Mexico, Philippines
Flexible Tape Stainless Steel Strip	Singapore, South Korea, NY 12203 (USA), Malaysia

›Material Properties

Chemical Composition of perforated stainless steel strips

Scroll to see all columns →

Grade	Grade_2	C	Mn	Si	P	S	Cr	Mo	Ni	N	Ti	Fe
304	min.						18.0		8.0
304	max.	0.08	2.0	0.75	0.045	0.030	20.0		10.5	0.10
304L	min.						18.0		8.0
304L	max.	0.030	2.0	0.75	0.045	0.030	20.0		12.0	0.10
304H	min.	0.04					18.0		8.0
304H	max.	0.010	2.0	0.75	0.045	0.030	20.0		10.5
SS 310		0.015 max	2 max	0.015 max	0.020 max	0.015 max	24.00 26.00	0.10 max	19.00 21.00	54.7 min
SS 310S		0.08 max	2 max	1.00 max	0.045 max	0.030 max	24.00 26.00	0.75 max	19.00 21.00	53.095 min
SS 310H		0.04 0.10	2 max	1.00 max	0.045 max	0.030 max	24.00 26.00		19.00 21.00	53.885 min
316	min.						16.0	2.03.0	10.0
316	max.	0.035	2.0	0.75	0.045	0.030	18.0	2.03.0	14.0
316L	min.						16.0	2.03.0	10.0
316L	max.	0.035	2.0	0.75	0.045	0.030	18.0	2.03.0	14.0
316TI		0.08 max	10.00 14.00	2.0 max	0.045 max	0.030 max	16.00 18.00	0.75 max	2.00 3.00
317		0.08 max	2 max	1 max	0.045 max	0.030 max	18.00 20.00	3.00 4.00				57.845 min
SS 317L		0.035 max	2.0 max	1.0 max	0.045 max	0.030 max	18.00 20.00	3.00 4.00	11.00 15.00			57.89 min
SS 321		0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	17.00 19.00		9.00 12.00	0.10 max	5(C+N) 0.70 max
SS 321H		0.04 0.10	2.0 max	1.0 max	0.045 max	0.030 max	17.00 19.00		9.00 12.00	0.10 max	4(C+N) 0.70 max
347/ 347H		0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	17.00 20.00		9.0013.00
410	min.						11.5
410	max.	0.15	1.0	1.00	0.040	0.030	13.5		0.75
446	min.						23.0			0.10
446	max.	0.2	1.5	0.75	0.040	0.030	30.0		0.50	0.25
904L	min.						19.0	4.00	23.00	0.10
904L	max.	0.20	2.00	1.00	0.045	0.035	23.0	5.00	28.00	0.25

Mechanical Properties of SA240 SS Thin Strips

col_1	col_2	col_3	col_4	col_5	col_6
Grade	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
304/ 304L	8.0 g/cm3	1400 °C (2550 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
304H	8.0 g/cm3	1400 °C (2550 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	40 %
310 / 310S / 310H	7.9 g/cm3	1402 °C (2555 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	40 %
306/ 316H	8.0 g/cm3	1400 °C (2550 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
316L	8.0 g/cm3	1399 °C (2550 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
317	7.9 g/cm3	1400 °C (2550 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
321	8.0 g/cm3	1457 °C (2650 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
347	8.0 g/cm3	1454 °C (2650 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
904L	7.95 g/cm3	1350 °C (2460 °F)	Psi 71000 , MPa 490	Psi 32000 , MPa 220	35 %

Equivalent Grade of stainless steel seam strips

Scroll to see all columns →

col_1	col_2	col_3	col_4	col_5	col_6	col_7	col_8
STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
SS 304	1.4301	S30400	SUS 304	304S31	08Х18Н10	Z7CN18‐09	X5CrNi18-10
SS 304L	1.4306 / 1.4307	S30403	SUS 304L	3304S11	03Х18Н11	Z3CN18‐10	X2CrNi18-9 / X2CrNi19-11
SS 304H	1.4301	S30409	–	–	–	–	–
SS 310	1.4841	S31000	SUS 310	310S24	20Ch25N20S2	–	X15CrNi25-20
SS 310S	1.4845	S31008	SUS 310S	310S16	20Ch23N18	–	X8CrNi25-21
SS 310H	–	S31009	–	–	–	–	–
SS 316	1.4401 / 1.4436	S31600	SUS 316	316S31 / 316S33	–	Z7CND17‐11‐02	X5CrNiMo17-12-2 / X3CrNiMo17-13-3
SS 316L	1.4404 / 1.4435	S31603	SUS 316L	316S11 / 316S13	03Ch17N14M3 / 03Ch17N14M2	Z3CND17‐11‐02 / Z3CND18‐14‐03	X2CrNiMo17-12-2 / X2CrNiMo18-14-3
SS 316H	1.4401	S31609	–	–	–	–	–
SS 316Ti	1.4571	S31635	SUS 316Ti	320S31	08Ch17N13M2T	Z6CNDT17‐123	X6CrNiMoTi17-12-2
SS 317	1.4449	S31700	SUS 317	–	–	–	–
SS 317L	1.4438	S31703	SUS 317L	–	–	–	X2CrNiMo18-15-4
SS 321	1.4541	S32100	SUS 321	–	–	–	X6CrNiTi18-10
SS 321H	1.4878	S32109	SUS 321H	–	–	–	X12CrNiTi18-9
SS 347	1.4550	S34700	SUS 347	–	08Ch18N12B	–	X6CrNiNb18-10
SS 347H	1.4961	S34709	SUS 347H	–	–	–	X6CrNiNb18-12
SS 904L	1.4539	N08904	SUS 904L	904S13	STS 317J5L	Z2 NCDU 25-20	X1NiCrMoCu25-20-5

›Tolerances

Tolerance of Width of SS 304 Strip Coil

col_1	col_2
W < 100 mm	100 mm ≦ W < 1000 mm
± 0.10 mm	± 0.25 mm
