Stainless Steel Chequered Plate

Available Stainless Steel Chequered Plate in Thickness 0.1-180 mm. Stockist and supplier of SS Perforated Sheet of POSCO at Dealer price. View Sizes & Dimensions of Stainless Diamond Chequer Plate

Stainless Steel

On This Page

Specification Format of Stainless Steel Chequered Plate Chemical Structure of ss chequered plate Mechanical Behaviour of stainless chequer plate Equivalent of SS Corrugated Perforated Sheet Dimensions of Stainless Diamond Chequer Plate ASTM A240 Perforated Sheet Weight Chart ASME SA240 Chequer plates Size Chart

Gallery

Stainless Steel Chequered Plate in Detail

Technical Data

Full Specifications

›Finishes & Forms

Specification Format of Stainless Steel Chequered Plate

col_1	col_2
Specifications	ASTM A240 / ASME SA240
Standard	JIS, AISI, ASTM, GB, DIN, EN, etc
Manufacturer	POSCO, Aperam, Jindal Stainless, DKC Korea, Thyssenkrup, Baosteel, TISCO, Arcelor Mittal, VDM, Nippon Metal, Outokumpu
Thickness	0.3~10.0mm
Form	Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange)
Export to	Dubai, Singapore, Indonesia, Ukraine, Korea, Iran, India, Saudi Arabia, Thailand, Egypt, Oman, Spain, Canada, USA, Ireland, Brazil, Peru, etc
Surface	the surface and finish of ss Plates: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hair line, sand blast, Brush, etching, etc
Width	1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length	2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
End	Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)

›Material Properties

Chemical Structure of ss chequered plate

Scroll to see all columns →

Grade	Grade_2	C	Mn	Si	P	S	Cr	Mo	Ni	N	Ti	Fe
304	min.						18.0		8.0
304	max.	0.08	2.0	0.75	0.045	0.030	20.0		10.5	0.10
304L	min.						18.0		8.0
304L	max.	0.030	2.0	0.75	0.045	0.030	20.0		12.0	0.10
304H	min.	0.04					18.0		8.0
304H	max.	0.010	2.0	0.75	0.045	0.030	20.0		10.5
SS 310		0.015 max	2 max	0.015 max	0.020 max	0.015 max	24.00 26.00	0.10 max	19.00 21.00	54.7 min
SS 310S		0.08 max	2 max	1.00 max	0.045 max	0.030 max	24.00 26.00	0.75 max	19.00 21.00	53.095 min
SS 310H		0.04 0.10	2 max	1.00 max	0.045 max	0.030 max	24.00 26.00		19.00 21.00	53.885 min
316	min.						16.0	2.03.0	10.0
316	max.	0.035	2.0	0.75	0.045	0.030	18.0	2.03.0	14.0
316L	min.						16.0	2.03.0	10.0
316L	max.	0.035	2.0	0.75	0.045	0.030	18.0	2.03.0	14.0
316TI		0.08 max	10.00 14.00	2.0 max	0.045 max	0.030 max	16.00 18.00	0.75 max	2.00 3.00
317		0.08 max	2 max	1 max	0.045 max	0.030 max	18.00 20.00	3.00 4.00				57.845 min
SS 317L		0.035 max	2.0 max	1.0 max	0.045 max	0.030 max	18.00 20.00	3.00 4.00	11.00 15.00			57.89 min
SS 321		0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	17.00 19.00		9.00 12.00	0.10 max	5(C+N) 0.70 max
SS 321H		0.04 0.10	2.0 max	1.0 max	0.045 max	0.030 max	17.00 19.00		9.00 12.00	0.10 max	4(C+N) 0.70 max
347/ 347H		0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	17.00 20.00		9.0013.00
410	min.						11.5
410	max.	0.15	1.0	1.00	0.040	0.030	13.5		0.75
446	min.						23.0			0.10
446	max.	0.2	1.5	0.75	0.040	0.030	30.0		0.50	0.25
904L	min.						19.0	4.00	23.00	0.10
904L	max.	0.20	2.00	1.00	0.045	0.035	23.0	5.00	28.00	0.25

Mechanical Behaviour of stainless chequer plate

col_1	col_2	col_3	col_4	col_5	col_6
Grade	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
304/ 304L	8.0 g/cm3	1400 °C (2550 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
304H	8.0 g/cm3	1400 °C (2550 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	40 %
310 / 310S / 310H	7.9 g/cm3	1402 °C (2555 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	40 %
306/ 316H	8.0 g/cm3	1400 °C (2550 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
316L	8.0 g/cm3	1399 °C (2550 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
317	7.9 g/cm3	1400 °C (2550 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
321	8.0 g/cm3	1457 °C (2650 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
347	8.0 g/cm3	1454 °C (2650 °F)	Psi 75000 , MPa 515	Psi 30000 , MPa 205	35 %
904L	7.95 g/cm3	1350 °C (2460 °F)	Psi 71000 , MPa 490	Psi 32000 , MPa 220	35 %

›Technical Data

Equivalent of SS Corrugated Perforated Sheet

Scroll to see all columns →

col_1	col_2	col_3	col_4	col_5	col_6	col_7	col_8
STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
SS 304	1.4301	S30400	SUS 304	304S31	08Х18Н10	Z7CN18‐09	X5CrNi18-10
SS 304L	1.4306 / 1.4307	S30403	SUS 304L	3304S11	03Х18Н11	Z3CN18‐10	X2CrNi18-9 / X2CrNi19-11
SS 304H	1.4301	S30409	–	–	–	–	–
SS 310	1.4841	S31000	SUS 310	310S24	20Ch25N20S2	–	X15CrNi25-20
SS 310S	1.4845	S31008	SUS 310S	310S16	20Ch23N18	–	X8CrNi25-21
SS 310H	–	S31009	–	–	–	–	–
SS 316	1.4401 / 1.4436	S31600	SUS 316	316S31 / 316S33	–	Z7CND17‐11‐02	X5CrNiMo17-12-2 / X3CrNiMo17-13-3
SS 316L	1.4404 / 1.4435	S31603	SUS 316L	316S11 / 316S13	03Ch17N14M3 / 03Ch17N14M2	Z3CND17‐11‐02 / Z3CND18‐14‐03	X2CrNiMo17-12-2 / X2CrNiMo18-14-3
SS 316H	1.4401	S31609	–	–	–	–	–
SS 316Ti	1.4571	S31635	SUS 316Ti	320S31	08Ch17N13M2T	Z6CNDT17‐123	X6CrNiMoTi17-12-2
SS 317	1.4449	S31700	SUS 317	–	–	–	–
SS 317L	1.4438	S31703	SUS 317L	–	–	–	X2CrNiMo18-15-4
SS 321	1.4541	S32100	SUS 321	–	–	–	X6CrNiTi18-10
SS 321H	1.4878	S32109	SUS 321H	–	–	–	X12CrNiTi18-9
SS 347	1.4550	S34700	SUS 347	–	08Ch18N12B	–	X6CrNiNb18-10
SS 347H	1.4961	S34709	SUS 347H	–	–	–	X6CrNiNb18-12
SS 904L	1.4539	N08904	SUS 904L	904S13	STS 317J5L	Z2 NCDU 25-20	X1NiCrMoCu25-20-5

ASME SA240 Chequer plates Size Chart

Size (in inches)	Size (in mm)
.125"	3.18mm
.134"	3.40mm
.156"	3.96mm
.187"	4.75mm
.250"	6.35mm
.312"	7.92mm
.375"	9.53mm
.500"	12.7mm
.601"	15.9mm
.750"	19.1mm
.875"	22.2mm
1"	25.4mm
1.125"	28.6mm
1.250"	31.8mm
1.500"	38.1mm
1.750"	44.5mm
2"	50.8mm
2.500"	63.5mm
3"	76.2mm

View material dispatch in the following countries

col_1	col_2
3mm 410 stainless steel chequered plate	Indonesia, Philippines, Dammam -KSA, Belgium
2b Finish 2.0mm stainless steel Chequered plate	France, Europe, Qatar, Thailand
ss Design Sheets	Germany, Thailand, Czechia, Malaysia
Structural Steel Chequered Steel Sheet	USA, Bangladesh, Malaysia, Finland
304 Stainless steel Floor Plate 2mm 3mm	Saudi Arabia (KSA), Kuwait, South Africa, Brazil
perforated metal stainless steel plate	South Africa, Singapore, Bahrain, Singapore
Embossing Spring Tread Plate	Australia, UK, Philippines, Nigeria
ss perforated metal sheet	Malaysia, Hong Kong, Oman, UAE
Perforated Metal Mesh Sheet	Italy, Iran, Chile, Singapore
904l stainless steel Checker Sheet	Turkey, Norway, United Arab Emirates (UAE), Malaysia
stainless steel 304 composition Diamond Tread Plate	Malaysia, Russia, Netherlands, Dubai
1.8-8.0mm Checkered Iron Sheet Chequered Sheet	Spain, Mexico, Egypt, UK
304 Perforated Stainless steel plate 3X1000X2000mm	Europe, Malaysia, United Kingdom -UK, UAE
decorative metal Chequer Sheet	Canada, Poland, UK, Ellington -the United States
perforated ss grill mesh sheet	Malaysia, Canada, Philippines, Singapore
Anti-Slip Steel Checkered Plate	Japan, Romania, Europe, Malaysia
Cold Roll 0.3mm Stainless Steel 316 Chakkar Plate	Colombia, Malaysia, Sweden, China
304 2B Finish Stainless Steel Chequered Sheet	Taiwan, Los Alamos -Mexico, Malaysia, Philippines
2mm Stainless Steel Perforated Metal Screen Sheet	South Korea, NY 12203 (USA), Singapore, Malaysia

›Dimensions & Weight

Dimensions of Stainless Diamond Chequer Plate

Plate Surface finish	Gauge (in)	Width (max in)
2B – Cold rolled, heat treated, pickled, skin passed Plate	10–24	72*
2D – Cold rolled, heat treated, pickled plate	12–24	60
BA Mexinox only	18–28	48
Polished plate (not brushed)	11–24	60
Temper rolled plate Mexinox only	13–29	48

Metric Dimensions

Plate Surface finish	Thickness (mm)	Width (max mm)
2B – Cold rolled, heat treated, pickled, skin passed plate	0.25–8.0	2032
2D – Cold rolled, heat treated, pickled plate	0.4–6.35	1524
2E – Cold rolled, heat treated, mechanically descaled plate	0.4–8.0	2032
2R – Cold rolled, bright annealed plate	0.25–3.5	1524
2H – Work hardened plate	0.4–6.35	1524
Polished, brushed plate	0.5–4.0	1524

ASTM A240 Perforated Sheet Weight Chart

Thickness	Plate Weight per Unit Area	Density
3/16 inches	0.06000 lbs/in²42.184176 kg/m²	0.315 lbs/in³8.72 g/cm³
1/4 inches	0.08 lbs/in²56.245568 kg/m²	0.315 lbs/in³8.72 g/cm³
3/8 inches	0.121 lbs/in²85.0714216 kg/m²	0.315 lbs/in³8.72 g/cm³
1/2 inches	0.161 lbs/in²113.1942056 kg/m²	0.315 lbs/in³8.72 g/cm³
5/8 inches	0.196 lbs/in²137.8016416 kg/m²	0.315 lbs/in³8.72 g/cm³
3/4 inches	0.235 lbs/in²165.221356 kg/m²	0.315 lbs/in³8.72 g/cm³
7/8 inches	0.274 lbs/in²192.6410704 kg/m²	0.315 lbs/in³8.72 g/cm³
1 inches	0.313 lbs/in²220.0607848 kg/m²	0.315 lbs/in³8.72 g/cm³
1 1/4 inches	0.391 lbs/in²274.9002136 kg/m²	0.315 lbs/in³8.72 g/cm³
1 1/2 inches	0.47 lbs/in²330.442712 kg/m²	0.315 lbs/in³8.72 g/cm³
1 3/4 inches	0.549 lbs/in²385.9852104 kg/m²	0.315 lbs/in³8.72 g/cm³
2 inches	0.627 lbs/in²440.8246392 kg/m²	0.315 lbs/in³8.72 g/cm³
2 1/4 inches	0.705 lbs/in²495.664068 kg/m²	0.315 lbs/in³8.72 g/cm³
2 1/2 inches	0.784 lbs/in²551.2065664 kg/m²	0.315 lbs/in³8.72 g/cm³
2 3/4 inches	0.862 lbs/in²606.0459952 kg/m²	0.315 lbs/in³8.72 g/cm³
3 inches	0.941 lbs/in²661.5884936 kg/m²	0.315 lbs/in³8.72 g/cm³
