Stainless Steel 316 Pipe

Stainless Steel 316 Pipe

ISO Certified Stainless Steel 316 Pipe Suppliers in India. Buy UNS S31600 schedule 40 Tubing at best price, Manufacturer of STM A213 TP316 Seamless/ Welded Tube. SA312 TP316 ERW Pipe Price List.

Stainless Steel

On This Page

Gallery

Stainless Steel 316 Pipe in Detail

Technical Data

Full Specifications

›Technical Data

Stainless Steel 316 Pipe Specification Table

ASTM / ASME StandardsASTM A269 / ASME SA269 ASTM A312 / ASME SA312
Pipe FormRound, Square, Hollow, Rectangular, Hydraulic, Straight Pipes Etc.
Pipe/ Tube LengthSingle Random, Double Random & Cut Length.
Pipe/ Tube ScheduleSCH5, SCH10, SCH40, STD, SCH80, SCH160
Pipe FinishPolished, AP (Annealed & Pickled), BA (Bright & Annealed), MF
EFW Pipe size5.0 mm - 1219.2 mm
EndPlain End, Beveled End, Treaded.
Welded Tube Size6.35 mm OD To 152 mm OD
Swg & Bwg10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg.
MarkingAll Pipes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.)
Material Test Certificates (MTC)Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2
Tubing wall thickness0.020" –0.220", (special wall thicknesses available)
Tube LengthSingle Random, Double Random, Standard & Cut length
EndPlain End, Beveled End, Treaded
MarkingAll tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.)
Tube TypeSeamless, ERW, EFW, Welded, Fabricated
FinishPolished, AP (Annealed & Pickled), BA (Bright & Annealed), MF
Tube FormRound, Coil, Square, Rectangular, Boiler, Hydraulic, Straight or ‘U’ bent Tubes, Hollow, LSAW Tubes Etc.
ApplicationOil Tube, Gas Tube, Fluid Tube, Boiler and Heat exchanger

Size Chart of Stainless Steel 316 Round Tube

WallSizes ( O.D.)
.0101/16" , 1/8" , 3/16"
.0201/16" , 1/8" , 3/16" , 1/4" , 5/16" , 3/8"
.0121/8"
.0161/8" , 3/16"
.0281/8" , 3/16" , 1/4" , 5/16" , 3/8" , 1/2" , 3/4" , 1" , 1 1/2" , 2"
.0351/8" , 3/16" , 1/4" , 5/16" , 3/8" , 7/16" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 2" , 2 1/4"
.0493/16" , 1/4" , 5/16" , 3/8" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/8" , 1 1/4" , 1 1/2" , 1 5/8" , 2" , 2 1/4"
.0651/4" , 5/16" , 3/8" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 1 3/4" , 2" , 2 1/2" , 3"
.0831/4" , 3/8" , 1/2" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 1 7/8" , 2" , 2 1/2" ,3"
.0951/2" , 5/8" , 1" , 1 1/4" , 1 1/2" , 2"
.1091/2" , 3/4" , 1" , 1 1/4" , 1 1/2" , 2"
.1201/2" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 2" , 2 1/4" , 2 1/2" , 3"
.1253/4" , 1" , 1 1/4" , 1 1/2" , 2" , 3" , 3 1/4"
.1341"
.2503"
.3753 1/2"

We Supply Stainless Steel 316 Pipe in Following Countries

col_1col_2
316 2b surface seamless or welded stainless steel pipeItaly, Singapore, Chile, Iran,
20mm diameter stainless steel pipe 316 mirror polishedUnited Arab Emirates (UAE), Turkey, Norway
316 grade 6 inch welded polished stainless steel pipeFrance, Thailand, Europe, Qatar
200x200 316 stainless steel Square tubeUSA, Malaysia, Finland, Bangladesh,
316 welding stainless steel pipesDammam -KSA, Indonesia, Belgium, Philippines
316 Medical Stainless Steel Capillary TubeQatar, France, Thailand, Europe
ASTM A249 TP316 Boiler TubesUK, Nigeria, Philippines, Australia,
316 stainless steel shell and tubeOman, Hong Kong, Malaysia
Thickness 9.0mm aisi 316 seamless stainless steel pipeSingapore, Egypt, UK, Mexico, Spain
ASTM A312 TP316 Elliptical and Oval PipeUnited Kingdom -UK, Europe, Malaysia
Custom Size 4 Inch SS 316 Stainless Steel Welded TubeRussia, Malaysia, Netherlands
316 Mirror Finish Stainless Steel PipeKuwait, South Africa, Saudi Arabia (KSA), Brazil
ASTM A213 316 Seamless TubeSingapore, South Africa, Bahrain
AISI 316 Stainless Steel ERW PipeEllington -United States, Canada, UK
›Dimensions & Weight

Weight Chart of ASTM A312 SS 316 Pipe

Scroll to see all columns →

PIPE SIZEOD IN INCHESA.S.A. Pipe SchedulesA.S.A. Pipe Schedules_2A.S.A. Pipe Schedules_3A.S.A. Pipe Schedules_4A.S.A. Pipe Schedules_5A.S.A. Pipe Schedules_6A.S.A. Pipe Schedules_7A.S.A. Pipe Schedules_8A.S.A. Pipe Schedules_9A.S.A. Pipe Schedules_10A.S.A. Pipe Schedules_11A.S.A. Pipe Schedules_12
PIPE SIZEOD IN INCHES5s510s1040s & Std.406080s & E.H.80120160DBL E.H.
1/8.405.035.1383.049.1863.049.1863.068.2447068.24470.95.31450.95.3145
1/4.540.049.2570.065.3297.065.3297.088.4248088.4248.119.5351.119.5351
3/8.675.049.3276.065.4235.065.4235.091.5676.091.5676.126.7338.126.7338
1/2.840.065.5383.065.5383.083.6710.083.6710.109.8510.109.8510.1471.088.1471.088.1871.304.2941.714
3/41.050.065.6838.065.6838.083.8572.083.8572.1131.131.1131.131.1541.474.1541.474.2181.937.3082.441
11.315.065.8678.065.8678.1091.404.1091.404.1331.679.1331.679.1792.172.1792.172.2502.844.3583.659
1-1/41.660.0651.107.0651.107.1091.806.1091.806.1402.273.1402.273.1912.997.1912.997.2503.765.3825.214
1-1/21.900.0651.274.0651.274.1092.085.1092.085.1452.718.1452.718.2003.631.2003.631.2814.859.4006.408
22.375.0651.604.0651.604.1092.638.1092.638.1543.653.1543.653.2185.022.2185.022.3437.444.4369.029
2-1/22.875.0832.475.0832.475.1203.531.1203.531.2035.793.2035.793.2767.661.2767.661.37510.01.55213.70
33.500.0833.029.0833.029.1204.332.1204.332.2167.576.2167.576.30010.25.30010.25.43714.32.60018.58
3-1/24.000.0833.472.0833.472.1204.973.1204.973.2269.109.2269.109.31812.51.31812.51.63622.85
44.500.0833.915.0833.915.1205.613.1205.613.23710.79.23710.79.28112.66.33714.98.33714.98.43719.01.53122.51.67427.54
4-1/25.000.24712.53.35517.61.71032.53
55.563.1096.349.1096.349.1347.770.1347.770.25814.62.25814.62.37520.78.37520.78.50027.04.62532.96.75038.55
66.625.1097.585.1097.585.1349.290.1349.290.28018.97.28018.97.43228.57.43228.57.56236.39.71845.30.86453.16
77.625.30123.57.50038.05.87563.08
Medium Type = Wall thickness in inches Bold Type = Steel weight per foot in poundsMedium Type = Wall thickness in inches Bold Type = Steel weight per foot in poundsMedium Type = Wall thickness in inches Bold Type = Steel weight per foot in poundsMedium Type = Wall thickness in inches Bold Type = Steel weight per foot in poundsMedium Type = Wall thickness in inches Bold Type = Steel weight per foot in poundsMedium Type = Wall thickness in inches Bold Type = Steel weight per foot in poundsMedium Type = Wall thickness in inches Bold Type = Steel weight per foot in poundsMedium Type = Wall thickness in inches Bold Type = Steel weight per foot in poundsMedium Type = Wall thickness in inches Bold Type = Steel weight per foot in poundsMedium Type = Wall thickness in inches Bold Type = Steel weight per foot in poundsMedium Type = Wall thickness in inches Bold Type = Steel weight per foot in poundsMedium Type = Wall thickness in inches Bold Type = Steel weight per foot in poundsMedium Type = Wall thickness in inches Bold Type = Steel weight per foot in poundsMedium Type = Wall thickness in inches Bold Type = Steel weight per foot in pounds

DIN 1.4401 Seamless Tubes Dimension Table

Scroll to see all columns →

NominalO.D. Inches10s1040s & Std4080s & E.H.80160
1/8.405.049.049.068.068.095.095
1/4.540.065.065.088.088.119.119
3/8.675.065.065.091.091.126.126
1/2.840.083.083.109.109.147.147.187
3/41.050.083.083.113.113.154.154.218
11.315.109.109.133.133.179.179.250
1 1/41.660.109.109.140.140.191.191.250
1 1/21.900.109.109.145.145.200.200.281
22.375.109.109.154.154.218.218.343
2 1/22.875.120.120.203.203.276.276.375
33.500.120.120.216.216.300.300.437
3 1/24.000.120.120.226.226.318.318
44.500.120.120.237.237.337.337.531
4 1/25.000.247.355
55.563.134.134.258.258.375.375.625
66.625.134.134.280.280.432.432.718
77.625.301.500
88.625.148.148.322.322.500.500.906
99.625.342.500
1010.750.165.165.365.365.500.5931.125
1111.750.375.500
1212.750.180.180.375.406.500.6871.312
1414.000.188.250.375.437.500.7501.406
1616.000.188.250.375.500.500.8431.593
1818.000.188.250.375.562.500.9371.781
›Pressure Ratings

316 Stainless Steel Tube Pressure Rating

Scroll to see all columns →

OD inchesAve. Wall inchesMin Yield Strength (PSI)Min Tensile Strength (PSI)Theoretical Burst Pressure * (PSI)Working Pressure (PSI) 25% of BurstTheoretical Yield Point ** (PSI)Collapse Pressure *** (PSI)
0.2500.02030,00075,00014,2863,5715,7144,416
0.2500.02830,00075,00021,6495,4128,6605,967
0.2500.03530,00075,00029,1677,29211,6677,224
0.2500.04930,00075,00048,35512,08919,3429,455
0.2500.06530,00075,00081,25020,31332,50011,544
0.3750.02030,00075,0008,9552,2393,5823,029
0.3750.02830,00075,00013,1663,2925,2664,145
0.3750.03530,00075,00017,2134,3036,8855,077
0.3750.04930,00075,00026,5346,63410,6146,816
0.3750.06530,00075,00039,7969,94915,9188,597
0.5000.02030,00075,0006,5221,6302,6092,316L
0.5000.02830,00075,0009,4592,3653,7843,172
0.5000.03530,00075,00012,2093,0524,8843,906
0.5000.04930,00075,00018,2844,5717,3135,316L
0.5000.06530,00075,00026,3516,58810,5416,786
0.5000.08330,00075,00037,2759,31914,9108,307
0.6250.02030,00075,0005,1281,2822,0511,859
0.6250.02830,00075,0007,3811,8452,9532,568
0.6250.03530,00075,0009,4592,3653,7843,172
0.6250.04930,00075,00013,9473,4875,5794,335
0.6250.06530,00075,00019,6974,9247,8795,591
0.6250.08330,00075,00027,1246,78110,8506,910
0.6250.09530,00075,00032,7598,19013,1037,734
0.6250.10930,00075,00040,17210,04316,0698,639
0.7500.02830,00075,0006,0521,5132,4212,156
0.7500.03530,00075,0007,7211,9303,0882,669
0.7500.04930,00075,00011,2732,8184,5093,664
0.7500.06530,00075,00015,7263,9316,2904,749
0.7500.08330,00075,00021,3185,3308,5275,905
0.7500.09530,00075,00025,4466,36210,1796,637
0.7500.10930,00075,00030,7337,68312,2937,453
0.7500.12030,00075,00035,2948,82414,1188,064
0.8750.02030,00075,0003,5938981,4371,340
0.8750.02830,00075,0005,1281,2822,0511,859
0.8750.03530,00075,0006,5221,6302,6092,316L
0.8750.04930,00075,0009,4592,3653,7843,172
0.8750.06530,00075,00013,0873,2725,2354,126
0.8750.08330,00075,00017,5604,3907,0245,152
0.8750.09530,00075,00020,8035,2018,3215,807
0.8750.10930,00075,00024,8866,2219,9546,543
0.8750.12030,00075,00028,3467,08711,3397,100
1.0000.02830,00075,0004,4491,1121,7801,633
1.0000.03530,00075,0005,6451,4112,2582,027
1.0000.04930,00075,0008,1492,0373,2592,796
1.0000.06530,00075,00011,2072,8024,4833,647
1.0000.08330,00075,00014,9283,7325,9714,567
1.0000.09530,00075,00017,5934,3987,0375,159
1.0000.10930,00075,00020,9085,2278,3635,827
1.0000.12030,00075,00023,6845,9219,4746,336
1.0000.13430,00075,00027,4596,86510,9846,963
1.2500.03530,00075,0004,4491,1121,7801,633
1.2500.04930,00075,0006,3801,5952,5522,260
1.2500.06530,00075,0008,7052,1763,4822,958
1.2500.08330,00075,00011,4852,8714,5943,719
1.2500.09530,00075,00013,4433,3615,3774,213
1.2500.10930,00075,00015,8433,9616,3374,776
1.2500.12030,00075,00017,8224,4557,1295,207
1.2500.13430,00075,00020,4685,1178,1875,742
1.5000.03530,00075,0003,6719181,4691,367
1.5000.04930,00075,0005,2431,3112,0971,896
1.5000.06530,00075,0007,1171,7792,8472,487
1.5000.08330,00075,0009,3332,3333,7333,136
1.5000.09530,00075,00010,8782,7194,3513,559
1.5000.10930,00075,00012,7543,1885,1014,043
1.5000.12030,00075,00014,2863,5715,7144,416
1.5000.13430,00075,00016,3154,0796,5264,881
1.5000.14830,00075,00018,4394,6107,3755,336
1.7500.03530,00075,0003,1257811,2501,176
1.7500.04930,00075,0003,8649661,5461,434
1.7500.06530,00075,0006,0191,5052,4072,146
1.7500.08330,00075,0007,8601,9653,1442,711
1.7500.09530,00075,0009,1352,2843,6543,080
1.7500.10930,00075,00010,6722,6684,2693,504
1.7500.12030,00075,00011,9212,9804,7683,832
1.7500.13430,00075,00013,5633,3915,4254,242
1.7500.14830,00075,00015,2683,8176,1074,645
1.7500.16530,00075,00017,4304,3576,9725,124
2.0000.03530,00075,0002,7206801,0881,032
2.0000.04930,00075,0003,8649661,5461,434
2.0000.06530,00075,0005,2141,3032,0861,887
2.0000.08330,00075,0006,7881,6972,7152,387
2.0000.09530,00075,0007,8731,9683,1492,715
2.0000.10930,00075,0009,1752,2943,6703,092
2.0000.12030,00075,00010,2272,5574,0913,384
2.0000.13430,00075,00011,6052,9014,6423,751
2.0000.14830,00075,00013,0283,2575,2114,111
2.0000.16530,00075,00014,8203,7055,9284,542
›Material Properties

Stainless Steel Type 316 Pipe Chemical Properties

Scroll to see all columns →

GradeCMnSiPSCrMoNiFe
SS 3160.08 max2.0 max1.0 max0.045 max0.030 max16.00 - 18.002.00 - 3.0011.00 - 14.0067.845 min

Mechanical Properties of SS 316 Pipe

DensityMelting PointTensile StrengthYield Strength (0.2%Offset)Elongation
8.0 g/cm31400 °C (2550 °F)Psi - 75000 , MPa - 515Psi - 30000 , MPa - 20535 %

Equivalent Grades of UNS S31600 Welded Pipe

Scroll to see all columns →

STANDARDWERKSTOFF NR.UNSJISBSGOSTAFNOREN
SS 3161.4401 / 1.4436S31600SUS 316316S31 / 316S33-Z7CND17-11-02X5CrNiMo17-12-2 / X3CrNiMo17-13-3
›Tolerances

SS 316 Pipe/ Tube Wall Thickness Tolerance

col_1col_2col_3
NPSASTM A312 WT Tolerance, %ASTM A312 WT Tolerance, %
NPS+–
1/8-2 1 /22012.5
3~18, t/D≤ 5%22.512.5
3~18, t/D> 5%1512.5
≥ 20, welded17.512.5
≥ 20, seamless, t/D≤ 5%22.512.5
≥ 20, seamless, t/D> 5%1512.5

Diameter Tolerance of 316 Stainless Steel Tubing & Pipe

col_1col_2col_3col_4col_5
NPSASTM A312 OD ToleranceASTM A312 OD ToleranceASTM A312 OD ToleranceASTM A312 OD Tolerance
NPS++––
NPSinchmminchmm
1/8~1 1 /21/64(0.015)0.41/32(0.031)0.8
> 1 1 /2~41/32(0.031)0.81/32(0.031)0.8
> 4~81/16(0.062)1.61/32(0.031)0.8
> 8~183/32(0.093)2.41/32(0.031)0.8
> 18~261/8(0.125)3.21/32(0.031)0.8
> 26~345/32(0.156)41/32(0.031)0.8
> 34~483/16(0.187)4.81/32(0.031)0.8
Stainless Steel 316 Pipe
Stainless Steel 316 Pipe

Get a Price

Request a quote for this item

Specify the grade, size, quantity and governing standard, and we'll confirm stock and pricing — typically within the same working day.

Request a Quote for Stainless Steel 316 Pipe

Contact

Send us the spec

Grade, form, size and quantity — that's all we need to confirm stock and quote. Reach us directly, or use the form below.

Enquiry FormReply same working day
Direct Contact

Head Office

Shop No. 5, Ravi Estate, Keval Kantha Road, Near Gujarat Bottling Road, Industrial Area, Rakhial, Ahmedabad, Gujarat – 380023, India

Phone / WhatsApp

+91 93240 06771

Working Hours

Monday – Saturday8:00 AM – 8:00 PM

SundayClosed
