Inconel 825 Pipe

Inconel 825 Pipe

Know About Accurate Sizes and Schedule of Inconel 800 Seamless Tube. Iso Certified Inconel 825 Pipe Supplier in India as Per Asme B36.19 Standard, Check Specification.

Nickel Alloys

On This Page

Gallery

Inconel 825 Pipe in Detail

Specification

Features & Applications

Inconel 825 Seamless Pipe Standard

  • ASTM B163
  • DIN 17751
  • ASTM B423
  • VdTÜV 432
  • ASTM B829
  • ISO 6207
  • BS 3074NA16

Inconel 800 Seamless Tube Standard

  • ASTM B163
  • BS 3074NA15
  • ASTM B407
  • VdTÜV 412
  • ASTM B829
  • ISO 6207
  • ASME N-20

Inconel 800H Seamless Pipe Application

  • Chemical Processing
  • Petro Processing
  • Electrical Resistance
  • Thermal Processing
  • Power Generation

Inconel 800 Seamless Pipe Density

  • 7.94 g/cm3
  • 0.287 lb/in.3

Incoloy 800 Pipe Melting Range

  • 2475 to 2525 °F
  • 1357 to 1385 °C

Inconel 825 Seamless Tube Density

  • 8.14 g/cm3
  • 0.294 lb/in.3

Incoloy 825 Pipe Melting Range

  • 2500 to 2550 °F
  • 1370 to 1400 °C

Nickel Alloy 800H ERW Pipe Density

  • 7.94 g/cm3
  • 0.287 lb/in.3

Inconel 800H Seamless Tube Melting Range

  • 2475 to 2525 °F
  • 1357 to 1385 °C

Incoloy Alloy 800 Round Pipe Dimensional Standard

  • SUS
  • JIS
  • ASTM
  • EN
  • DIN
  • GB

Incoloy 825 Square Pipe Common Trade Name

  • Alloy 2242
  • Incoloy® 825
  • Sanicro® 41
  • Inc825

ASTM B407 UNS N08800 Rectangle Tube Dimensional Specification

  • ASME B36.10
  • ASME B36.19

Incoloy 800H Pipe Common Trade Name

  • Sanicro® 31HT
  • Incoloy® 800 H/HT

Incoloy 825 Welded Pipe Equivalent Standard

  • UNS No : N08825
  • British Standard : NA 16
  • Europe : NiCr21Mo
  • Werkstoff nr. : 2.4858
  • France : NFE30C20DUM
  • Japanese : NCF 825
  • Russia : ЭП703

ASME SB407 Incoloy 800H Pipe Equivalent Standard

  • UNS No : N08800
  • Werkstoff nr. : 1.4876
  • JIS : NCF 800
  • GOST : ЭИ670
  • BS : NA 15
  • EN : X10NiCrAlTi32-20
  • OR : XH32T

Incoloy Alloy 800H Annealed Pipe Equivalent Standard

  • WERKSTOFF NR. : 1.4958 / 1.4876
  • JIS : NCF 800H
  • UNS : N08810
  • GOST : ЭИ670
  • BS : NA 15(H)
  • OR : XH32T
  • EN : X5NiCrAlTi31-20

Alloy Incoloy 825 Clad Pipe Hot Working Temperature

  • 870 to 1180°C

Incoloy 825 Tube Annealing Temperature

  • 930°C to 980°C
  • 1700°F to 1800°F

Supporting documents for Alloy Incoloy 800 Cold Finished Pipe

  • MTC EN 10204 3.1/3.2
  • Check List
  • Labeling verification
  • Inspection plan
  • Inspection reports
  • Origin

825 Inconel Hot Finished Pipe Annealed Temperature Range

  • 1150 to 1175°C
  • 2100 to 2150°F

800H Inconel Seam Welded Pipe Price Term

  • FOB
  • CIF
  • CFR

Testing requirements for Nickel Alloy 800H Bright Annealed Pipe

  • Ultrosonic test
  • 100% eddy current test
  • 100% Radiographic Test

Inconel Alloy 800 Solution Annealed Pipe Finishing Treatment

  • Cold Finished
  • Hot Finished

Heat Treatment for 825 Inconel Cold Finished Seamless Pipe

  • +LC
  • +A
  • +SRA
  • Q+T
  • +N

Inconel 800 Seam Welded Pipe End

  • Beveled
  • Threaded Ends
  • Square Ends
  • Plain Ends

Alloy 800H Exhaust Pipe Services

  • Cut to Length
  • Welding
  • Machining
  • Threading
  • Beveling

Hastelloy C276 Welded Pipe Length

  • Cut Length
  • Single
  • Double Random
  • Standard

Inconel 800H Tube Manufacturing Types

  • CEW
  • EFW
  • CDW
  • LSAW
  • Seamless
  • Welded
  • Electric Resistance Welded
  • Fabricated
  • DOM

Alloy Incoloy 800H ERW Tube Form

  • Coiled
  • Straight
  • Hollow
  • U Shape
  • Hydraulic
  • Rectangular
  • Round
  • Square

Origin standards for ASTM B423 UNS N08810 Pipe

  • American
  • Janpanese
  • European
  • Russia

Marking

  • Heat Number
  • Schedule or Wall Thickness
  • Manufacturer’s Name
  • Material Grade
  • Specification
  • Nominal Size
  • Method of Manufacturing

Incoloy WERKSTOFF NR. 2.4858 Pipe Equipment

  • Sand-blasting machine
  • Bending machine
  • Pushing Machine
  • Electric bevelling machine
  • Press machine

Incoloy 800 Round Pipe Welding Method

  • MAG
  • GMAW
  • MIG
  • TIG
  • SMAW
  • FCAW

UNS N08800 Incoloy 800 Thin Wall Pipe Testing

  • PMI Testing
  • Flattening Test
  • Pitting Resistance Test
  • Micro and MacroTest
  • Chemical Analysis
  • IGC Test
  • Hardness Test
  • Dye Penetrant
  • Mechanical Testing
  • X-Ray
  • Flaring Test
  • UT

Incoloy 800 Grade SCH 40 Seamless Pipe Packaging

  • PE Fabric Bundles
  • Crates
  • Wrapped in plastic
  • Bundles
  • Wooden Boxes
  • Custom

Certification of Schedule 40 ASTM B167 UNS N08800 Incoloy Pipe

  • MTC EN 10204 3.1/3.2
  • Third Party Inspection Report
  • Form A for GSP
  • Heat Treatment Charts
  • DFARS compliant
  • Commercial Invoice
  • HS Code
  • Raw Materials Certificate

Available As

Incoloy Alloy 825 annealed tubeNickel 800H hot finished pipeUNS N08800 annealed pipeInconel 2.4858 exhaust pipeInconel Alloy 800H cold finished pipeIncoloy 825 square pipeAlloy 825 round pipeNickelvac 825 seam welded pipeNicrofer 4241 tubeAlloy 800 square tubingIncoloy 800 extruded tubeInconel 1.4876 solution annealed pipeAlloy 800H seamless pipeNickel Alloy 825 clad pipeInconel 825 welded tubeUNS N08810 exhaust tubingWerkstoff NR. 1.4876 seamless tubeUNS N08825 tubingNickel 800 bright annealed pipeInconel 1.4958 seam welded pipeNickel 825 rectangular pipeWerkstoff NR. 1.4958 cold finished seamless pipeAlloy 825 hot finished seamless pipeNickel Alloy 800 redrawn tubeIncoloy Alloy 800 welded pipeInconel Alloy 825 cold drawn pipe

Technical Data

Full Specifications

›Technical Data

Incoloy 800 Seamless Pipe Size Chart

Scroll to see all columns →

NPS1/81/43/81/23/411 1/41 1/222 1/233 1/244 1/256789101112141618
OD in inch.405.54.675.841.051.3151.661.92.3752.8753.544.555.5636.6257.6258.6259.6251 .7511.7512.75141618
10.049.065.065.083.083.109.109.109.109.12.12.12.12.134.134.148.165.18.25.25.25
10S.049.065.065.083.083.109.109.109.109.12.12.12.12.134.134.148.165.18.188.188.188
40S & STD.068.088.091.109.113.133.14.145.154.203.216.226.237.247.258.28.301.322.342.365.375.375.375.375.375
40.068.088.091.109.113.133.14.145.154.203.216.226.237.258.28.322.365.406.437.5.562
80.095.119.126.147.154.179.191.2.218.276.3.318.337.375.432.5.593.687.75.843.937
80S & E.H..095.119.126.147.154.179.191.2.218.276.3.318.337.355.375.432.5.5.5.5.5.5.5.5.5
160.187.218.25.25.281.343.375.437.531.625.718.9061.1251.3121.4061.5931.781

Alloy 825 Pipe Schedule Chart

Size in InchSchedules
1/4"Sch 10 to 80
3/8"Sch 10 to 80
1/2"5 to 160, XXH
3/4"10 to 160, XXH
1/8"SCH 40, 80
1"5 to 160, XXH
1-1/4"10 to 160, XXH
1-1/2"10 to160, XXH
2"10 to 160, XXH
2 1/2"10 to 160, XXH
3"5 to 160, XXH
4"10 to 160, XXH
5"10 to 160, XXH
6"5 to 160, XXH
8 ”5 to 160, XXH
3 1/2"SCH 10 to 160, XXH
10"10 to 80, TRUE 80
12"10, 20, 40, TRUE40, SCH80
14"SCH10, SCH40
16"SCH10, SCH40
18" IPSSCH-40

Incoloy 800 vs 825

PropertyIncoloy 800Incoloy 825
MatrixNickel, Iron, ChrominumNickel, Iron, Chrominum, Copper, Molybdenum
Density7.94 g/cm³8.14 g/cm³
PurityLess pure than 825More pure than 800
Corrosion ResistanceLess resistance than 825More resistance than 800
PriceLow priceHigh price
Temperature RangeUp to 1100°C (2000°F)Up to 870°C (1600°F)
Mechanical PropertiesHigh strength Excellent creep resistance at elevated temperaturesGood mechanical properties
ApplicationsHeat exchangers, industrial furnaces, petrochemical processing, power generationChemical processing, pollution control, oil and gas recovery, marine environments
WeldabilityGood weldabilityGood weldability

Nickel Alloy 800H Round Pipe Equivalent Standard

Scroll to see all columns →

StandardNorth AmericaGermanyRussiaJapanEuropeRussia_2British StandardFrance
StandardUNSWERKSTOFF NR.ORJISENGOSTBSAFNOR
Incoloy 800 PipeN088001.4876XH32TNCF 800X10NiCrAlTi32-20ЭИ670NA 15Z8NC32-21
Incoloy 825N088252.4858NCF 825NiCr21MoЭП703NA 16NFE30C20DUM
Incoloy 800HT PipeN088111.4859 / 1.4876XH32TNCF 800HTX8NiCrAlTi32-21ЭИ670NA 15(HT)–
Incoloy 800H PipeN088101.4958 / 1.4876XH32TNCF 800HX5NiCrAlTi31-20ЭИ670NA 15(H)Z8NC33-21
›Dimensions & Weight

Inconel 825 Pipe Weight Chart

Scroll to see all columns →

NPS in inchesOutside DiameterOutside Diameter_2Wall ThicknessWall Thickness_2WeightWeight_2
NPS in inchesmillimeterinchesmillimeterinchesLb/ftkilogram/meter
1/2"21.842.769.109.8511.268
3/4"271.052.87.1131.1311.684
1"331.3153.378.1331.6792.501
1 1/4"421.663.556.142.2733.385
1 1/2"481.93.683.1452.7184.048
2"602.3753.912.1543.6535.441
2 1/2"732.8755.516.2035.7938.629
3"893.55.486.2167.57611.284
4"1144.56.02.2371 .7916.073
6"1686.6254.775.18812.92419.252
5.563.21914.98322.318
7.112.2818.97458.263
9.525.37525.03137.285
8"2198.6254.775.18816.9425.233
5.563.21919.66129.286
7.036.27724.69636.786
9.525.37533.04149.216
10"2731 .754.775.18821.20731.588
6.35.2528.03541.759
8.738.34438.23156.946
11.125.43848.23871.852
15.088.59464.42995.969
12"32412.754.775.18825.22237.57
6.35.2533.37549.713
7.925.31241.44561.735
1 .312.40653.52579.727
14"356144.775.18827.73241.308
6.35.2536.71354.685
7.925.31245.61167.939
11.125.43863.44194.498
15.875.62589.278132.983
16”406164.775.18821.74847.29
6.35.2542.05362.639
7.925.31252.27577.866
9.525.37562.57893.213
12.7.582.77123.289
18"457185.563.21941.58861.948
7.137.28153.17679.208
9.525.3757 .588105.144
12.7.593.45139.198
15.875.625115.978172.754
20"508206.35.2552.73378.547
7.925.31265.60497.719
11.125.43891.508136.305
15.088.594123.11183.378
17.475.688141.901211.368
24"610246.35.2563.41394.456
7.925.31218.932117.573
11.125.43811 .219164.176
15.875.625156.028232.41
19.05.75186.233277.401
30"762306.35.2579.433118.318
7.925.31298.925147.353
11.125.438138.286205.983
15.875.625196.078292.066
19.05.75234.293348.988
36"914366.35.2595.453142.18
7.925.312118.918177.133
11.125.438166.353247.79
15.875.625236.128351.723
19.05.75282.35342 .576
42"1067427.925.312138.911206.914
12.7.5221.6133.097
48"1219489.525.37519 .738284.112
12.7.5253.65377.822
22.225.87544 .383655.969
›Material Properties

ASTM B423 UNS N08825 Square Pipe Mechanical Property

GradeYield Strength, minTensile Strength, minElongation (% in 50mm) min
800/HT30000 Psi 205 MPa75000 Psi 520 MPa30
82532000 Psi 220 MPa80000 Psi 550 MPa30

Incoloy 800 Steel Pipe Chemical Composition

Scroll to see all columns →

GradeGrade_2MnNiCFeSiCrSCuAl-TiTi
Incoloy 800 Pipemin.–30–39.5–19–.15
Incoloy 800 Pipemax.1.535.1–123015.60
Incoloy 825 Pipemin.--22-19.5-1.5.6
Incoloy 825 Pipemax.105-.523.501531.2
Incoloy 800HT Pipemin.–300639.5–19–.85/ .25
Incoloy 800HT Pipemax.1.535.1–1230151.20/ .60
Incoloy 800H Pipemin.–300539.5–19–.15
Incoloy 800H Pipemax.1.535.1–123015.60
