EN 10210 Pipe

EN 10210 Pipe Supplier in India, Check EN 10210-1 Seamless Pipes Size. View Dimensions and sizes of Schedule 40 EN 10210-2 Pipe

API 5L

On This Page

Gallery

EN 10210 Pipe in Detail

Technical Data

›Technical Data

col_1	col_2
Standard	BS EN 10210
Type	Hot Finished Structural (HFS tube)
Export to	Netherlands, Colombia, Japan, Chile, Saudi Arabia (KSA), Germany, Iraq France, United Kingdom (UK), Egypt, China, Nigeria, Hong Kong, Kuwait, United States (USA), Indonesia, Jordan, Kenya, Greece, Bangladesh, Turkey, Spain, Italy, Sri Lanka, Australia, South Africa, South Korea, Iran, Pakistan, Belgium, Nepal, Oman, Malaysia, Philippines, Poland, Canada, Brazil, Taiwan, Singapore, Mexico, United Arab Emirates (UAE), Myanmar (Burma), Romania, Qatar, Vietnam, Thailand
Thickness	0.5mm - 40mm
Length	6000-14000 mm
Tolerances	Thickness : (All size +/- 10%)
Size Range	10mm x 10mm to 800mm x 800mm

Size mm	kg/m	Size mm_2	kg/m_2
40 x 20 x 2.0	1.68	40 x 20 x 2.5	2.03
40 x 20 x 3.0	2.36	40 x 25 x 1.5	1.44
40 x 25 x 2.0	1.89	40 x 25 x 2.5	2.23
50 x 25 x 2.0	2.21	50 x 25 x 2.5	2.72
50 x 25 x 3.0	3.22	50 x 30 x 2.5	2.92
50 x 30 x 3.0	3.45	50 x 30 x 4.0	4.46
50 x 40 x 3.0	3.77	60 x 40 x 2.0	2.93
60 x 40 x 2.5	3.71	60 x 40 x 3.0	4.39
60 x 40 x 4.0	5.72	70 x 50 x 2	3.56
70 x 50 x 2.5	4.39	70 x 50 x 3.0	5.19
70 x 50 x 4.0	6.71	80 x 40 x 2.5	4.26
80 x 40 x 3.0	5.34	80 x 40 x 4.0	6.97
80 x 40 x 5.0	8.54	80 x 50 x 3.0	5.66
80 x 50 x 4.0	7.34	90 x 50 x 3.0	6.28
90 x 50 x 3.6	7.46	90 x 50 x 5.0	10.11
100 x 50 x 2.5	5.63	100 x 50 x 3.0	6.75
100 x 50 x 4.0	8.86	100 x 50 x 5.0	10.90
100 x 60 x 3.0	7.22	100 x 60 x 3.6	8.59
100 x 60 x 5.0	11.70	120 x 80 x 2.5	7.65
120 x 80 x 3.0	9.03	120 x 80 x 4.0	12.00
120 x 80 x 5.0	14.80	120 x 80 x 6.0	17.60
120 x 80 x 8.0	22.9	150 x 100 x 5.0	18.70
150 x 100 x 6.0	22.30	150 x 100 x 8.0	29.10
150 x 100 x 10.0	35.70	160 x 80 x 5.0	18.00
160 x 80 x 6.0	21.30	160 x 80 x 8.0	27.90
200 x 100 x 5.0	22.70	200 x 100 x 6.0	27.00
200 x 100 x 8.0	35.4	200 x 100 x 10.0	43.60
250 x 150 x 5.0	30.5	250 x 150 x 6.0	38.2
250 x 150 x 8.0	48.0	250 x 150 x 10	59.3
300 x 200 x 6.0	48.10	300 x 200 x 8.0	60.50
300 x 200 x 10.0	75.00	400 x 200 x 8.0	73.10
400 x 200 x 10.0	90.70	400 x 200 x 16	142.00

›Material Properties

Scroll to see all columns →

col_1	col_2	col_3	col_4	col_5	col_6	col_7
Steel Grade
Steel Grade	C Maximum	Mn Maximum	P Maximum	Si Maximum	S Maximum	N Maximum
S235JRH	0.17	0.040	1.40	-	0.040	0.009
S355J0H	0.22	0.035	1.60	0.55	0.035	0.009
S275J2H	0.20	0.030	1.50	-	0.030	–
S355J2H	0.22	0.030	1.60	0.55	0.030	–
S275J0H	0.20	0.035	1.50	-	0.035	0.009
S355K2H	0.22	0.030	1.60	0.55	0.030	–

Scroll to see all columns →

col_1	col_2	col_3	col_4	col_5	col_6	col_7
EN 10210 S355J2H	Mechanical Strength	Mechanical Strength	Mechanical Strength	Impact Energy	Impact Energy	Impact Energy
EN 10210 S355J2H	Yield Strength	Elongation (%))	Tensile Strength	Test Temperature in celsius	Test Temperature in celsius	Test Temperature in celsius
EN 10210 S355J2H	Yield Strength	Elongation (%))	Tensile Strength	-20	0	20
S355J2H	355	22	510-680	27	–	–
S275J0H	275	23	410-560	–	27	–
S275J2H	275	23	410-560	27	–	–
S235JRH	235	26	360-510	–	–	27
S355J0H	355	22	510-680	–	27	–
S355K2H	355	22	510-680	40	–	–

›Dimensions & Weight

col_1	col_2	col_3	col_4
Nominal Bore	Outside diameter	Thickness	Weight
mm	mm	mm	kg/m
15	21.3	2.00	0.95
15	21.3	2.60	1.21
15	21.3	3.20	1.44
20	26.9	2.30	1.38
20	26.9	2.60	1.56
20	26.9	3.20	1.87
25	33.7	2.60	1.98
25	33.7	3.20	0.24
25	33.7	4.00	2.93
32	42.4	2.60	2.54
32	42.4	3.20	3.01
32	42.4	4.00	3.79
40	48.3	2.90	3.23
40	48.3	3.20	3.56
40	48.3	4.00	4.37
50	60.3	2.90	4.08
50	60.3	3.60	5.03
50	60.3	5.00	6.19
65	76.1	3.20	5.71
65	76.1	3.60	6.42
65	76.1	4.50	7.93
80	88.9	3.20	6.72
80	88.9	4.00	8.36
80	88.9	4.80	9.90
100	114.3	3.60	9.75
100	114.3	4.50	12.20
100	114.3	5.40	14.50
125	139.7	4.50	15.00
125	139.7	4.80	15.90
125	139.7	5.40	17.90
150	165.1	4.50	17.80
150	165.1	4.80	18.90
150	165.1	5.40	21.30
150	168.3	5.00	20.1
150	168.3	6.3	25.2
150	168.3	8.00	31.6
150	168.3	10.00	39
150	168.3	12.5	48
200	219.1	4.80	25.38
200	219.1	6.00	31.51
200	219.1	8.00	41.67
200	219.1	10.00	51.59
250	273	6.00	39.51
250	273	8.00	52.30
250	273	10.00	64.59
300	323.9	6.30	49.36
300	323.9	8.00	62.35
300	323.9	10.00	77.44
