RTJ Flange

Ready Stock of ASME B16.5 RTJ Flange in India, Manufacturer of Stainless Steel Ring Type Joint Flange & Class 2500 Rtj Flange at factory price, Check Carbon Steel Ring Type Joint Blind Flange Sizes

Types of Flanges

On This Page

Spec Chart of ASME B16.5 RTJ Flange Class 150 RTJ Flange Dimensions Class 300 Rtj Flange Dimensions Class 400 Weld neck RTJ Flange Dimensions Table Class 600 Rtj Flange Dimensions Class 900 Rtj Flange Dimensions Chart Class 1500 Rtj Flange Dimensions Ring Type Joint Blind Flange Pressure Chart Ring Type Joint Flange Torque Chart Working Temperature and Pressure of RTJ Blind Flange Application of Ring Joint Flange Advantages & Disadvantages of ASME B16.5 RTJ Flange

Gallery

RTJ Flange in Detail

Specification

Features & Applications

Application of Ring Joint Flange

Desalination Equipment
Flue Gas Scrubbing Equipment
Marine Applications
Pulp & Paper Mill Equipment
Offshore Oil production/technology
Chemical process pressure vessels

Advantages & Disadvantages of ASME B16.5 RTJ Flange

It is considered to be most efficient flange used in process piping systems.
Ring and groove design enhances internal pressures sealing capacity of the connecting flanges
Specifically applicable to severe services involving high pressures
Ring type joint is most expensive configuration
May require considerable space

Technical Data

Full Specifications

›Technical Data

Spec Chart of ASME B16.5 RTJ Flange

col_1	col_2
Size	1/2″ to 48″
Standards	MSS SP44, ASA, ANSI B16.47 Series A & B, ANSI B16.5, API-605, AWWA, Custom Drawings.
Pressure Ratings	PN6, PN10, PN16, PN25, PN40, PN64 etc.
Pressure class	150#, 300#, 600#, 1500#
Dimensions	BS3293, Table D, E, F, & H, ANSI, PN6, 10, 16, 25, 64 BS10, BS4504, MSS- SP-44, DIN Standards
Flange Face Type Manufacturer	Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
Export to	Iran, Ukraine, USA, Spain, India, Saudi Arabia, Egypt, Ireland, Brazil, Indonesia, Korea, Oman, Dubai, Singapore, Canada, Thailand, Peru, etc
Coating/Surface Treatment	Oil Black Paint, Yellow Transparent, Anti-rust Paint, Zinc Plated, Cold and Hot Dip Galvanized.
Test	Hydrostatic testing machine, X-ray detector, Direct-reading Spectrograph, UI trasonic flaw detector, Magnetic particle detector

Ring Type Joint Blind Flange Pressure Chart

Scroll to see all columns →

Temperature (F°)	Class 150	Class 300	Class 400	Class 600	Class 900	Class 1500	Class 2500
-20 to 100	285	740	985	1480	2220	3705	6170
300	230	655	870	1310	1965	3270	5450
200	260	680	905	1360	2035	3395	5655
400	200	635	845	1265	1900	3170	5280
600	140	570	755	1135	1705	2840	4730
500	170	605	805	1205	1810	3015	5025
650	125	550	730	1100	1650	2745	4575
750	95	505	675	1015	1520	2535	4230
700	110	530	710	1060	1590	2655	4425
800	80	410	550	825	1235	2055	3430
1000	20	85	115	170	255	430	715
900	50	230	305	460	690	1150	1915
850	65	320	425	640	955	1595	2655
950	35	135	185	275	410	685	1145

Ring Type Joint Flange Torque Chart

Scroll to see all columns →

Flanges / NPS	No of / Bolt	Bolts / size	Bolts Stress / (MPa)	Torque N-m / μ=0.09 / Copperslip	Torque N-m / μ=0.14 / Chesterton / Nickel	Torque N-m / μ=0.225 / Unlubricated
½''	4	½	276	40	59	90
1''	4	½	276	40	59	90
¾''	4	½	276	40	59	90
1¼''	4	½	276	40	59	90
2''	4	⅝	276	79	116	178
1½''	4	½	276	40	56	90
2½''	4	⅝	276	79	116	178
4''	8	⅝	276	79	116	178
3''	4	⅝	276	79	116	178
5''	8	¾	276	139	203	313
8''	8	¾	276	139	203	313
6''	8	¾	276	139	203	313
10''	12	⅞	276	221	325	502
14''	12	1	276	330	485	748
12''	12	⅞	276	221	325	502
16''	16	1	276	330	485	748
20''	20	1 ⅛	276	479	708	1098
18''	16	1 ⅛	276	479	708	1098
24''	20	1 ¼	276	668	992	1543

Requirements and Materials country wise

col_1	col_2
carbon Steel rtj wn flange	Malaysia, Oman, Hong Kong, UAE
ansi b16.5 blind rtj flange class 150 to 2500	USA, Malaysia, Bangladesh, Finland
rtj 316 stainless steel flange	Saudi Arabia (KSA), South Africa, Kuwait, Brazil
Forged Welding Neck Raised Face Ring-Type Joint SS Flange	Turkey, United Arab Emirates (UAE), Norway, Malaysia
Steel Ring Type Joint Flange	Canada, UK, Poland, Ellington -United States
ansi class 1500 ring type joint rtj flange	Germany, Czechia, Thailand, Malaysia
En 1092-1:2007 Ring Joint Flange	Malaysia, Netherlands, Russia, Dubai
3 inch 1500 rtj flange	Taiwan, Malaysia, Los Alamos -Mexico, Philippines
4Inch 1500 LB RING TYPE JOINT Flange	Italy, Chile, Iran, Singapore
A350 Lf2 Class 900 Rtj Flange	South Korea, Singapore, NY 12203 (USA), Malaysia
ASME B16.5 Ring Type Joint Flange	South Africa, Bahrain, Singapore, Singapore
titanium ring butt welding ring flange joint	Indonesia, Dammam -KSA, Philippines, Belgium
RING TYPE JOINT FLANGE,BL,3",900#,A105N	France, Qatar, Europe, Thailand
class 2500 rtj flange	Europe, United Kingdom -UK, Malaysia, UAE
2 inch rtj flange	Australia, Philippines, UK, Nigeria
Ring Type Joint Reducing JIS B2291 Spacer Flanges	Spain, Egypt, Mexico, UK
A182 F11 Ring Type Joint Flanges	Malaysia, Philippines, Canada, Singapore
Forged steel ring type joint face flange	Colombia, Sweden, Malaysia, China
ANSI B16.36 Class 300 Orifice Forged Ring-Type Joint Flange	Japan, Europe, Romania, Malaysia

›Dimensions & Weight

Class 150 RTJ Flange Dimensions

Scroll to see all columns →

Sizes in In	Sizes in Millimeter	Welding Neck Length	Flange Thickness	RTJ Raised Face Diameter	Hub Outside Diameter	Width	RTJ Raised Face Height	Outer Diameter	PCD	Weld Neck Outside Diameter	Ring Joint Flange Pitch Diameter	Depth	Bore
		E	B	F	C	K	G	A	H	D	I	J	L
1/2	15	46	9.6	N/A	30	N/A	N/A	90	60.3	21.3	N/A	N/A	Weld Neck bore is derived from the pipe schedules
3/4	20	51	11.2	N/A	38	N/A	N/A	100	69.9	26.7	N/A	N/A
1 1/4	32	56	14.3	73	59	8.74	6.35	115	88.9	42.2	57.15	6.35
1	25	54	12.7	63.5	49	8.74	6.35	110	79.4	33.4	47.63	6.35
2	50	62	17.5	102	78	8.74	6.35	150	120.7	60.3	82.55	6.35
1 1/2	40	60	15.9	82.5	65	8.74	6.35	125	98.4	48.3	65.07	6.35
3 1/2	90	70	22.3	154	122	8.74	6.35	215	177.8	101.6	131.78	6.35
3	80	68	22.3	133	108	8.74	6.35	190	152.4	88.9	114.3	6.35
4	100	75	22.3	171	135	8.74	6.35	230	190.5	114.3	149.23	6.35
2 1/2	65	68	20.7	121	90	8.74	6.35	180	139.7	73	101.6	6.35
6	150	87	23.9	219	192	8.74	6.35	280	241.3	168.3	193.68	6.35
5	125	87	22.3	194	164	8.74	6.35	255	215.9	141.3	171.45	6.35
8	200	100	27	273	246	8.74	6.35	345	298.5	219.1	247.65	6.35
24	600	151	46.1	711	663	8.74	6.35	815	749.3	610	673.1	6.35
12	300	113	30.2	406	365	8.74	6.35	485	431.8	323.8	381	6.35
10	250	100	28.6	330	305	8.74	6.35	405	362	273	304.8	6.35
14	350	125	33.4	425	400	8.74	6.35	535	476.3	355.6	396.88	6.35
18	450	138	38.1	546	505	8.74	6.35	635	577.9	457.2	517.53	6.35
16	400	125	35	483	457	8.74	6.35	595	539.8	406.4	454.03	6.35
20	500	143	41.3	597	559	8.74	6.35	700	635	508	558.8	6.35

Class 300 Rtj Flange Dimensions

Scroll to see all columns →

Sizes in In	Sizes in Millimeter	Outer Diameter	Flange Thickness	Hub Outside Diameter	Weld Neck Outside Diameter	Welding Neck Length	RTJ Raised Face Diameter	RTJ Raised Face Height	PCD	Ring Joint Flange Pitch Diameter	Depth	Width	Bore
		A	B	C	D	E	F	G	H	I	J	K	L
1/2	15	95	12.7	38	21.3	51	51	5.54	66.7	34.14	5.54	7.14	Weld Neck bore is derived from the pipe schedules
1	25	125	15.9	54	33.4	60	70	6.35	88.9	50.8	6.35	8.74	Weld Neck bore is derived from the pipe schedules
3/4	20	115	14.3	48	26.7	56	63.5	6.35	82.6	42.88	6.35	8.74	Weld Neck bore is derived from the pipe schedules
1 1/4	32	135	17.5	64	42.2	64	79.5	6.35	98.4	60.33	6.35	8.74	Weld Neck bore is derived from the pipe schedules
2	50	165	20.7	84	60.3	68	108	7.92	127	82.55	7.92	11.91	Weld Neck bore is derived from the pipe schedules
1 1/2	40	155	19.1	70	48.3	67	90.5	6.35	114.3	68.27	6.35	8.74	Weld Neck bore is derived from the pipe schedules
2 1/2	65	190	23.9	100	73	75	127	7.92	149.2	101.6	7.92	11.91	Weld Neck bore is derived from the pipe schedules
3 1/2	90	230	28.6	133	101.6	79	159	7.92	184.2	131.78	7.92	11.91	Weld Neck bore is derived from the pipe schedules
3	80	210	27	117	88.9	78	146	7.92	168.3	123.83	7.92	11.91	Weld Neck bore is derived from the pipe schedules
4	100	255	30.2	146	114.3	84	175	7.92	200	149.23	7.92	11.91	Weld Neck bore is derived from the pipe schedules
6	150	320	35	206	168.3	97	241	7.92	269.9	211.12	7.92	11.91	Weld Neck bore is derived from the pipe schedules
5	125	280	33.4	178	141.3	97	210	7.92	235	180.98	7.92	11.91	Weld Neck bore is derived from the pipe schedules
8	200	380	39.7	260	219.1	110	302	7.92	330.2	269.88	7.92	11.91	Weld Neck bore is derived from the pipe schedules
12	300	520	49.3	375	323.8	129	413	7.92	450.8	381	7.92	11.91	Weld Neck bore is derived from the pipe schedules
10	250	445	46.1	321	273	116	356	7.92	387.4	323.85	7.92	11.91	Weld Neck bore is derived from the pipe schedules
24	600	915	68.3	702	610	167	749	11.13	812.8	692.15	11.13	16.66	Weld Neck bore is derived from the pipe schedules
14	350	585	52.4	425	355.6	141	457	7.92	514.4	419.1	7.92	11.91	Weld Neck bore is derived from the pipe schedules
18	450	710	58.8	533	457	157	575	7.92	628.6	533.4	7.92	11.91	Weld Neck bore is derived from the pipe schedules
16	400	650	55.6	483	406.4	144	508	7.92	571.5	469.9	7.92	11.91	Weld Neck bore is derived from the pipe schedules
20	500	775	62	587	508	160	635	9.53	685.8	584.2	9.53	13.49	Weld Neck bore is derived from the pipe schedules

Class 400 Weld neck RTJ Flange Dimensions Table

Scroll to see all columns →

Sizes in In	Sizes in Millimeter	Outer Diameter	Flange Thickness	Hub Outside Diameter	Weld Neck Outside Diameter	Welding Neck Length	RTJ Raised Face Diameter	RTJ Raised Face Height	PCD	Ring Joint Flange Pitch Diameter	Depth	Width	Bore
		A	B	C	D	E	F	G	H	I	J	K	L
1/2	15	95	14.3	38	21.3	52	51	5.54	66.7	34.14	5.54	7.14	Weld Neck bore is derived from the pipe schedules
1	25	125	17.5	54	33.4	62	70	6.35	88.9	50.8	6.35	8.74	Weld Neck bore is derived from the pipe schedules
3/4	20	115	15.9	48	26.7	57	63.5	6.35	82.6	42.88	6.35	8.74	Weld Neck bore is derived from the pipe schedules
1 1/4	32	135	20.7	64	42.2	67	79.5	6.35	98.4	60.33	6.35	8.74	Weld Neck bore is derived from the pipe schedules
2	50	165	25.4	84	60.3	73	108	7.92	127	82.55	7.92	11.9	Weld Neck bore is derived from the pipe schedules
1 1/2	40	155	22.3	70	48.3	70	90.5	6.35	114.3	68.27	6.35	8.74	Weld Neck bore is derived from the pipe schedules
2 1/2	65	190	28.6	100	73	79	127	7.92	149.2	101.6	7.92	11.9	Weld Neck bore is derived from the pipe schedules
3 1/2	90	230	35	133	101.6	86	159	7.92	184.2	131.78	7.92	11.9	Weld Neck bore is derived from the pipe schedules
3	80	210	31.8	117	88.9	83	146	7.92	168.3	123.83	7.92	11.9	Weld Neck bore is derived from the pipe schedules
4	100	255	35	146	114.3	89	175	7.92	200	149.23	7.92	11.91	Weld Neck bore is derived from the pipe schedules
6	150	320	41.3	206	168.3	103	241	7.92	269.9	211.12	7.92	11.91	Weld Neck bore is derived from the pipe schedules
5	125	280	38.1	178	141.3	102	210	7.92	235	180.98	7.92	11.91	Weld Neck bore is derived from the pipe schedules
8	200	380	47.7	260	219.1	117	302	7.92	330	269.88	7.92	11.91	Weld Neck bore is derived from the pipe schedules
12	300	520	57.2	375	323.8	137	413	7.92	450.8	381	7.92	11.91	Weld Neck bore is derived from the pipe schedules
10	250	445	54	321	273	124	356	7.92	387.4	323.85	7.92	11.91	Weld Neck bore is derived from the pipe schedules
24	600	915	76.2	702	610	175	749	11.13	812.8	692.15	11.13	16.66	Weld Neck bore is derived from the pipe schedules
14	350	585	60.4	425	355.6	149	457	7.92	514.4	419.1	7.92	11.91	Weld Neck bore is derived from the pipe schedules
18	450	710	66.7	533	457	165	575	7.92	628.6	533.4	7.92	11.91	Weld Neck bore is derived from the pipe schedules
16	400	650	63.5	483	406.4	152	508	7.92	571.5	469.9	7.92	11.91	Weld Neck bore is derived from the pipe schedules
20	500	775	69.9	587	508	168	635	9.53	685.8	584.2	9.53	13.49	Weld Neck bore is derived from the pipe schedules

Class 600 Rtj Flange Dimensions

Scroll to see all columns →

Sizes in In	Sizes in Millimeter	Outer Diameter	Flange Thickness	Hub Outside Diameter	Weld Neck Outside Diameter	Welding Neck Length	RTJ Raised Face Diameter	RTJ Raised Face Height	PCD	Ring Joint Flange Pitch Diameter	Depth	Width	Bore
		A	B	C	D	E	F	G	H	I	J	K	L
1/2	15	95	14.3	38	21.3	52	51	5.54	66.7	34.14	5.54	7.14	Weld Neck bore is derived from the pipe schedules
1	25	125	17.5	54	33.4	62	70	6.35	88.9	50.8	6.35	8.74	Weld Neck bore is derived from the pipe schedules
3/4	20	115	15.9	48	26.7	57	63.5	6.35	82.6	42.88	6.35	8.74	Weld Neck bore is derived from the pipe schedules
1 1/4	32	135	20.7	64	42.2	67	79.5	6.35	98.4	60.33	6.35	8.74	Weld Neck bore is derived from the pipe schedules
2	50	165	25.4	84	60.3	73	108	7.92	127	82.55	7.92	11.91	Weld Neck bore is derived from the pipe schedules
1 1/2	40	155	22.3	70	48.3	70	90.5	6.35	114.3	68.27	6.35	8.74	Weld Neck bore is derived from the pipe schedules
2 1/2	65	190	28.6	100	73	79	127	7.92	149.2	101.6	7.92	11.91	Weld Neck bore is derived from the pipe schedules
3 1/2	90	230	35	133	101.6	86	159	7.92	184.2	131.78	7.92	11.91	Weld Neck bore is derived from the pipe schedules
3	80	210	31.8	117	88.9	83	146	7.92	168.3	123.83	7.92	11.91	Weld Neck bore is derived from the pipe schedules
4	100	275	38.1	152	114.3	102	175	7.92	215.9	149.23	7.92	11.91	Weld Neck bore is derived from the pipe schedules
6	150	355	47.7	222	168.3	117	241	7.92	292.1	211.12	7.92	11.91	Weld Neck bore is derived from the pipe schedules
5	125	330	44.5	189	141.3	114	210	7.92	266.7	180.98	7.92	11.91	Weld Neck bore is derived from the pipe schedules
8	200	420	55.6	273	219.1	133	302	7.92	349.2	269.88	7.92	11.91	Weld Neck bore is derived from the pipe schedules
12	300	560	66.7	400	323.8	156	413	7.92	489	381	7.92	11.91	Weld Neck bore is derived from the pipe schedules
10	250	510	63.5	343	273	152	356	7.92	431.8	323.85	7.92	11.91	Weld Neck bore is derived from the pipe schedules
14	350	605	69.9	432	355.6	165	457	7.92	527	419.1	7.92	11.91	Weld Neck bore is derived from the pipe schedules
24	600	940	101.6	718	610	203	749	11.13	838.2	692.15	11.13	16.66	Weld Neck bore is derived from the pipe schedules
18	450	745	82.6	546	457	184	575	7.92	654	533.4	7.92	11.91	Weld Neck bore is derived from the pipe schedules
16	400	685	76.2	495	406.4	178	508	7.92	603.2	469.9	7.92	11.91	Weld Neck bore is derived from the pipe schedules
20	500	815	88.9	610	508	190	635	9.53	723.9	584.2	9.53	13.49	Weld Neck bore is derived from the pipe schedules

Class 900 Rtj Flange Dimensions Chart

Scroll to see all columns →

Sizes in In	Sizes in Millimeter	Outer Diameter	Flange Thickness	Hub Outside Diameter	Weld Neck Outside Diameter	Welding Neck Length	RTJ Raised Face Diameter	RTJ Raised Face Height	PCD	Ring Joint Flange Pitch Diameter	Depth	Width	Bore
		A	B	C	D	E	F	G	H	I	J	K	L
1/2	15	120	22.3	38	21.3	60	60.5	6.35	82.6	39.67	6.35	8.74	Weld Neck bore is derived from the pipe schedules
1	25	150	28.6	52	33.4	73	71.5	6.35	101.6	50.8	6.35	8.74	Weld Neck bore is derived from the pipe schedules
3/4	20	130	25.4	44	26.7	70	66.5	6.35	88.9	44.45	6.35	8.74	Weld Neck bore is derived from the pipe schedules
1 1/4	32	160	28.6	64	42.2	73	81	6.35	111.1	60.33	6.35	8.74	Weld Neck bore is derived from the pipe schedules
2	50	215	38.1	105	60.3	102	124	7.92	165.1	95.25	7.92	11.91	Weld Neck bore is derived from the pipe schedules
1 1/2	40	180	31.8	70	48.3	83	92	6.35	123.8	68.27	6.35	8.74	Weld Neck bore is derived from the pipe schedules
2 1/2	65	245	41.3	124	73	105	137	7.92	190.5	107.95	7.92	11.91	Weld Neck bore is derived from the pipe schedules
4	100	290	44.5	159	114.3	114	181	7.92	235	149.23	7.92	11.91	Weld Neck bore is derived from the pipe schedules
3	80	240	38.1	127	88.9	102	156	7.92	190.5	123.83	7.92	11.91	Weld Neck bore is derived from the pipe schedules
5	125	350	50.8	190	141.3	127	216	7.92	279.4	180.98	7.92	11.91	Weld Neck bore is derived from the pipe schedules
8	200	470	63.5	298	219.1	162	308	7.92	393.7	269.88	7.92	11.91	Weld Neck bore is derived from the pipe schedules
6	150	380	55.6	235	168.3	140	241	7.92	317.5	211.12	7.92	11.91	Weld Neck bore is derived from the pipe schedules
10	250	545	69.9	368	273	184	362	7.92	469.9	323.85	7.92	11.91	Weld Neck bore is derived from the pipe schedules
14	350	640	85.8	451	355.6	213	467	11.13	558.8	419.1	11.13	16.66	Weld Neck bore is derived from the pipe schedules
12	300	610	79.4	419	323.8	200	419	7.92	533.4	381	7.92	11.91	Weld Neck bore is derived from the pipe schedules
16	400	705	88.9	508	406.4	216	524	11.13	616	469.9	11.13	16.66	Weld Neck bore is derived from the pipe schedules
20	500	855	108	622	508	248	648	12.7	749.3	584.2	12.7	19.84	Weld Neck bore is derived from the pipe schedules
18	450	785	101.6	565	457	229	594	12.7	685.8	533.4	12.7	19.84	Weld Neck bore is derived from the pipe schedules
24	600	1040	139.7	749	610	292	772	15.88	901.7	692.15	15.88	26.97	Weld Neck bore is derived from the pipe schedules

Class 1500 Rtj Flange Dimensions

Scroll to see all columns →

Sizes in In	Sizes in Millimeter	Outer Diameter	Flange Thickness	Hub Outside Diameter	Weld Neck Outside Diameter	Welding Neck Length	RTJ Raised Face Diameter	RTJ Raised Face Height	PCD	Ring Joint Flange Pitch Diameter	Depth	Width	Bore
		A	B	C	D	E	F	G	H	I	J	K	L
1/2	15	120	22.3	38	21.3	60	60.5	6.35	82.6	39.67	6.35	8.74	Weld Neck bore is derived from the pipe schedules
1	25	150	28.6	52	33.4	73	71.5	6.35	101.6	50.8	6.35	8.74	Weld Neck bore is derived from the pipe schedules
3/4	20	130	25.4	44	26.7	70	66.5	6.35	88.9	44.45	6.35	8.74	Weld Neck bore is derived from the pipe schedules
1 1/4	32	160	28.6	64	42.2	73	81	6.35	111.1	60.33	6.35	8.74	Weld Neck bore is derived from the pipe schedules
2	50	215	38.1	105	60.3	102	124	7.92	165.1	95.25	7.92	11.91	Weld Neck bore is derived from the pipe schedules
1 1/2	40	180	31.8	70	48.3	83	92	6.35	123.8	68.27	6.35	8.74	Weld Neck bore is derived from the pipe schedules
2 1/2	65	245	41.3	124	73	105	137	7.92	190.5	107.95	7.92	11.91	Weld Neck bore is derived from the pipe schedules
4	100	310	54	162	114.3	124	194	7.92	241.3	161.93	7.92	11.91	Weld Neck bore is derived from the pipe schedules
3	80	265	47.7	133	88.9	117	168	7.92	203.2	136.53	7.92	11.91	Weld Neck bore is derived from the pipe schedules
5	125	375	73.1	197	141.3	156	229	7.92	292.1	193.68	7.92	11.91	Weld Neck bore is derived from the pipe schedules
8	200	485	92.1	292	219.1	213	318	11.13	393.7	269.88	11.13	16.66	Weld Neck bore is derived from the pipe schedules
6	150	395	82.6	229	168.3	171	248	9.53	317.5	211.14	9.53	13.49	Weld Neck bore is derived from the pipe schedules
10	250	585	108	368	273	254	371	11.13	482.6	323.85	11.13	16.66	Weld Neck bore is derived from the pipe schedules
14	350	750	133.4	495	355.6	298	489	15.88	635	419.1	15.88	26.97	Weld Neck bore is derived from the pipe schedules
12	300	675	123.9	451	323.8	283	438	14.27	571.5	381	14.27	23.01	Weld Neck bore is derived from the pipe schedules
16	400	825	146.1	552	406.4	311	546	17.48	704.8	469.9	17.48	30.18	Weld Neck bore is derived from the pipe schedules
20	500	985	177.8	641	508	356	673	17.48	831.8	584.2	17.48	33.32	Weld Neck bore is derived from the pipe schedules
18	450	915	162	597	457	327	613	17.48	774.7	533.4	17.48	30.18	Weld Neck bore is derived from the pipe schedules
24	600	1170	203.2	762	610	406	794	20.62	990.6	692.15	20.62	36.53	Weld Neck bore is derived from the pipe schedules

RTJ Flange

Get a Price

Request a quote for this item

Specify the grade, size, quantity and governing standard, and we'll confirm stock and pricing — typically within the same working day.

Request a Quote for RTJ Flange

Contact

Send us the spec

Grade, form, size and quantity — that's all we need to confirm stock and quote. Reach us directly, or use the form below.

Enquiry FormReply same working day

Direct Contact

Head Office

Shop No. 5, Ravi Estate, Keval Kantha Road, Near Gujarat Bottling Road, Industrial Area, Rakhial, Ahmedabad, Gujarat – 380023, India

Phone / WhatsApp

+91 93240 06771

exportompmo@gmail.com

Working Hours

Monday – Saturday8:00 AM – 8:00 PM

SundayClosed

col_1	col_2
Working Temperature	700/800 C°
Working Pressure	15,000 psi (103 MPa)
